The NXP MC9S08PL32CLF is an 8-bit microcontroller built around the S08 core, clocked at 20 MHz. That clock rate is enough to handle a LIN bus node, a UART-based sensor hub, or a simple PWM motor controller without needing a higher-tier part. The 32 KB on-chip Flash and 39 general-purpose I/O lines give it room for moderate firmware — think body-control modules, HVAC actuators, or industrial sensor interfaces.
That saves a second BOM line and one PCB trace.
Peripherals and connectivity — LINbus, SCI, UART, PWM
Connectivity includes LINbus, SCI, and UART/USART, making this a natural fit for LIN slave nodes in automotive body electronics — window lifts, seat adjusters, mirror controllers. The 12-channel 10-bit ADC covers analog inputs like potentiometer position or temperature sensing. Three PWM channels can drive small DC motors or LED dimmers directly. The peripheral set is deliberately lean: no USB, no CAN, no high-speed SPI — you pick this part when the application is a simple control loop with a LIN or UART link.
Lifecycle status — active, no LTB risk
NXP lists the MC9S08PL32CLF as Active.
