Littelfuse Inc. S6015L52TP
MPNS6015L52TP
Active
SCR 600V 15A ITO220AB
$3.09Ref. price · indicative, final on quote
PackagingTO-220-3 Full Pack, Isolated Tab
RoHSROHS3 Compliant
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| SCR type | Standard Recovery |
| Mounting | Through Hole |
| Voltage - off state | 600 V |
| Voltage - on state (Vtm) | 1.6 V |
| Voltage - gate trigger (Vgt) | 1.5 V |
| Current - hold (Ih) | 40 mA |
| Current - off state | 10 µA |
| Current - gate trigger (Igt) | 30 mA |
| Current - on state (It (AV)) | 9.5 A |
| Current - on state (It (RMS)) | 15 A |
| Current - non rep. surge 50, 60Hz | 188A, 225A |
| Operating temperature | -40°C ~ 125°C (TJ) |
| Package | Tube |
| Case | TO-220-3 Full Pack, Isolated Tab |
