DMN2004K-7
Diodes Incorporated
Tape & Reel (TR) Cut Tape (CT)-65°C ~ 150°C (TJ)N-Channel
Ref. price$0.3800
Lead time on requestGet quote ›
Diodes Incorporated DMN2 Series
56 variants · Diodes Incorporated
About the Diodes Incorporated Diodes Incorporated DMN2 Series series
The Diodes Incorporated Diodes Incorporated DMN2 Series series groups 56 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting type of Surface Mount, package of Tape & Reel (TR) Cut Tape (CT) and technology of MOSFET (Metal Oxide). Variants differ by case, current - continuous drain (Id) @ 25°C and drain to source voltage, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 3-XFDFN · 6-PowerUDFN · 6-UDFN Exposed Pad · 6-UFDFN Exposed Pad · 6-XFDFN Exposed Pad · 8-PowerTDFN · 8-PowerVDFN · 8-TSSOP (0.173\", 4.40mm Width) · SC-70, SOT-323 · SOT-563, SOT-666 · TO-236-3, SC-59, SOT-23-3
- Current - continuous drain (Id) @ 25°C
- 7.5A · 8.58A · 9A · 10.5A (Ta) · 18.1A (Tc) · 20A (Ta), 100A (Tc) · 200mA (Ta) · 300mA · 540mA · 540mA (Ta) · 630mA (Ta)
- Drain to source voltage
- 20 V · 20V
- FET feature
- - · Logic Level Gate
- Input capacitance (Ciss) (Max) @ vds
- - · 41 pF @ 3 V · 150 pF @ 16 V · 150pF @ 16V · 1495pF @ 10V · 1550pF @ 10V · 1779 pF @ 10 V · 5337 pF @ 10 V · 6495 pF @ 10 V
- Operating temperature
- -65°C ~ 150°C (TJ) · -55°C ~ 150°C (TJ)
- Rds on (Max) @ id, vgs
- 1.5Ohm @ 10mA, 4V · 4.6mOhm @ 13.5A, 4.5V · 11.6mOhm @ 8.5A, 4.5V · 13mOhm @ 4A, 4.5V · 14.5mOhm @ 9.4A, 4.5V · 15.5mOhm @ 4A, 4.5V · 550mOhm @ 540mA, 4.5V
- Vgs(th) (Max) @ id
- 1V @ 250µA · 1.1V @ 250µA · 1.2V @ 250µA · 900mV @ 100µA
Variant comparison
| Parameter | DMN2004K-7 | DMN2004VK-7 | DMN2004WKQ-7 | DMN2005DLP4K-7 | DMN2005LP4K-7 | DMN2005UFG-13 |
|---|---|---|---|---|---|---|
| Case | TO-236-3, SC-59, SOT-23-3 | SOT-563, SOT-666 | SC-70, SOT-323 | 6-XFDFN Exposed Pad | 3-XFDFN | 8-PowerVDFN |
| Current - continuous drain (Id) @ 25°C | 630mA (Ta) | 540mA | 540mA (Ta) | 300mA | 200mA (Ta) | 18.1A (Tc) |
| Drain to source voltage | 20 V | 20V | 20 V | 20V | 20 V | 20 V |
| FET feature | - | Logic Level Gate | - | - | - | - |
| Input capacitance (Ciss) (Max) @ vds | 150 pF @ 16 V | 150pF @ 16V | 150 pF @ 16 V | - | 41 pF @ 3 V | 6495 pF @ 10 V |
| Operating temperature | -65°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -65°C ~ 150°C (TJ) | -65°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) |
| Rds on (Max) @ id, vgs | 550mOhm @ 540mA, 4.5V | 550mOhm @ 540mA, 4.5V | 550mOhm @ 540mA, 4.5V | 1.5Ohm @ 10mA, 4V | 1.5Ohm @ 10mA, 4V | 4.6mOhm @ 13.5A, 4.5V |
| Vgs(th) (Max) @ id | 1V @ 250µA | 1V @ 250µA | 1V @ 250µA | 900mV @ 100µA | 900mV @ 100µA | 1.2V @ 250µA |
Shared specifications
- Mounting type
- Surface Mount
- Package
- Tape & Reel (TR) Cut Tape (CT)
- Technology
- MOSFET (Metal Oxide)
