MAX20087ATPA/VY+
Analog Devices
Surface Mount, Wettable FlankTray-40°C ~ 125°C
Ref. price$4.2
Lead time on requestGet quote
MAX2xxx RF & Wireless ICs
49 variants · Analog Devices
About the MAX2xxx RF & Wireless ICs
The Analog Devices MAX2xxx RF & Wireless ICs series groups 49 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by mounting, operating temperature and package, so you can match the exact mounting your application requires using the selection guide below.
Select a variant by
- Mounting
- Surface Mount · Surface Mount, Wettable Flank · Through Hole
- Operating temperature
- -40°C ~ 85°C · -40°C ~ 125°C · -40°C ~ 125°C (TA) · -40°C ~ 125°C (TJ) · 0°C ~ 70°C
- Package
- Tape & Reel (TR); Cut Tape (CT) · Tray · Tube
- Case
- 9-WFBGA, WLBGA · 12-WFDFN Exposed Pad · 16-SOIC (0.154\", 3.90mm Width) · 20-DIP (0.300\", 7.62mm) · 20-WFQFN Exposed Pad · 20-WQFN Exposed Pad · 24-WFQFN Exposed Pad · 28-TSSOP (0.173\", 4.40mm Width) Exposed Pad · 28-WFQFN Exposed Pad · 32-WFQFN Exposed Pad
- I/O channels
- 1 · 2 · 4 · 6 · 12
- Frequency
- 1MHz · 2kHz · 2.2MHz · 220kHz ~ 2.2MHz · 400kHz ~ 2.2MHz
- Topology
- Boost, SEPIC · Buck · Flyback, SEPIC, Step-Down (Buck), Step-Up (Boost) · Step-Down (Buck)
- Type
- DC DC Controller · Transceiver
Variant comparison
| Parameter | MAX20003CATPB/V+ | MAX20022ATIA+ | MAX20034ATIS/VY+ | MAX20075ATCA/V+T | MAX20087ATPA/VY+ | MAX20092ATJ/VY+ |
|---|---|---|---|---|---|---|
| Mounting | Surface Mount | Surface Mount | Surface Mount, Wettable Flank | Surface Mount | Surface Mount, Wettable Flank | Surface Mount, Wettable Flank |
| Operating temperature | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C | 0°C ~ 70°C | -40°C ~ 125°C | -40°C ~ 125°C |
| Package | Tray | Tube | Tray | Tape & Reel (TR); Cut Tape (CT) | Tray | Tray |
| Case | 20-WQFN Exposed Pad | 28-WFQFN Exposed Pad | 28-WFQFN Exposed Pad | 12-WFDFN Exposed Pad | 20-WFQFN Exposed Pad | 32-WFQFN Exposed Pad |
| I/O channels | 1 | 4 | 2 | 1 | — | 12 |
| Frequency | 220kHz ~ 2.2MHz | 2.2MHz | 220kHz ~ 2.2MHz | — | — | 2kHz |
| Topology | Buck | Buck | Buck | Buck | — | — |
| Type | — | — | — | — | — | DC DC Controller |
Request a quote on any MAX2xxx RF & Wireless ICs part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
