LTC4000IGN-1#PBF
Analog Devices
Tube-40°C ~ 125°C (TJ)PowerPath™
Ref. price$12.41
Lead time on requestGet quote
Analog Devices LTC40 Series
15 variants · Analog Devices
About the Analog Devices LTC40 Series
The Analog Devices LTC40 Series series groups 15 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common current - charging of Constant - Programmable and mounting of Surface Mount. Variants differ by battery chemistry, case and operating temperature, so you can match the exact battery chemistry your application requires using the selection guide below. All listed Analog Devices LTC40 Series part numbers are active and orderable.
Select a variant by
- Battery chemistry
- Lithium Ion · Lithium Ion/Polymer · Lithium Iron Phosphate · Multi-Chemistry
- Case
- 8-SOIC (0.154\", 3.90mm Width) · 8-WFDFN Exposed Pad · 10-TFSOP, 10-MSOP (0.118\", 3.00mm Width) Exposed Pad · 10-WFDFN Exposed Pad · 14-WFDFN Exposed Pad · 16-SSOP (0.154\", 3.90mm Width) · 16-WQFN Exposed Pad · 20-WFQFN Exposed Pad · 28-SSOP (0.154\", 3.90mm Width)
- Operating temperature
- -40°C ~ 85°C (TA) · -40°C ~ 125°C (TA) · -40°C ~ 125°C (TJ)
- Package
- Bulk · Tape & Reel (TR); Cut Tape (CT) · Tube
- Voltage
- 5.5V · 6.5V · 8V · 22V · 28V · 60V
- Number of cells
- 1 · 1 ~ 4 · 3
- Battery pack voltage
- 3.95V · 4.1V · 4.2V · 12.6V
- Charge current - max
- 1A · 1.5A · 250mA · 525mA · 950mA
Shared specifications
- Current - charging
- Constant - Programmable
- Mounting
- Surface Mount
Variant comparison
| Parameter | LTC4000IGN-1#PBF | LTC4002ES8-4.2#PBF | LTC4055EUF-1#PBF | LTC4058EDD-4.2#PBF | LTC4062EDD#PBF | LTC4068XEDD-4.2#PBF |
|---|---|---|---|---|---|---|
| Battery chemistry | Lithium Iron Phosphate | Lithium Ion | Lithium Ion | Lithium Ion | Lithium Ion | Lithium Ion |
| Case | 28-SSOP (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) | 16-WQFN Exposed Pad | 8-WFDFN Exposed Pad | 10-WFDFN Exposed Pad | 8-WFDFN Exposed Pad |
| Operating temperature | -40°C ~ 125°C (TJ) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Package | Tube | Tube | Tube | Tube | Tube | Tube |
| Voltage | 60V | 22V | 5.5V | 6.5V | 8V | 6.5V |
| Number of cells | — | 1 | 1 | 1 | 1 | 1 |
| Battery pack voltage | — | 4.2V | 4.1V | 4.2V | 4.2V | 4.2V |
| Charge current - max | — | — | 1A | 950mA | 1A | 950mA |
Request a quote on any Analog Devices LTC40 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
