Analog Devices MAX20019ATBA/V+T — DC-DC Power Modules
Technical Documents PDF / CAD
Manufacturer Datasheet (External) ↗
RoHS Compliant · Lead-Free EIA-481 Standard
Analog Devices / DC-DC Power Modules

MAX20019ATBA/V+T Automotive Buck Regulator, Dual 500mA

MPN MAX20019ATBA/V+T
End of Life Spot Stock · 24-48h Dispatch 100% Original Sealed

Maxim MAX20019ATBA/V+T, Series Automotive AEC-Q100, Step-Down, Buck, Fixed Output, Dual 500mA, 3.2MHz, 10-TDFN-EP (2x3), -40°C to 125°C.

In Stock: 20 pcs
MOQ: 1 pcs
Logistics: DHL / FedEx DAP (Global Express · 3-7d) Russia & CIS DDP (Door-to-Door Cleared)
Dispatch: Shenzhen / HK
Unit Price (USD)
$5.34 / pc
Direct Purchase Ready
Volume Pricing Breaks Confirmed upon quotation
1+ pcs
$5.34
10+ pcs
$4.58
Working on a production BOM or have a target unit price? Submit Target Price
Buy Now

$5.34 / ea

20 in stock — maximum per order · 3–4 days lead time

$4.58 / ea from 10 pcs
Upload Full BOM List
100% Original Sealed 45x Microscope QC 30-Day Warranty · COC USD T/T & PI · DAP/DDP
[SPEC] Essential Parameters Snapshot Full Specifications (15)
Package / Case 10-WFDFN Exposed Pad

Full Technical Specifications

15 Parameters
MAX20019ATBA/V+T specifications
Parameter / AttributeSpecification / Value
SeriesAutomotive, AEC-Q100
Output typeFixed
MountingSurface Mount
Voltage - input3.5V
Voltage - output (Min (Fixed))3.3V, 1.8V
Output current500mA, 500mA
Frequency - switching3.2MHz
I/O channels2
Operating temperature-40°C ~ 125°C
PackageTape & Reel (TR); Cut Tape (CT)
FunctionStep-Down
TopologyBuck
Case10-WFDFN Exposed Pad
Output configurationPositive
Synchronous rectifierNo
Series Sibling Variants

Analog Devices Automotive, AEC-Q100 Series Models

Sibling variants, package options, and speed/density grades in this Analog Devices semiconductor series. Active Shenzhen warehouse allocation and rapid 24-48h dispatch.

DS2431P-A1+T
Maxim Integrated DS2431P-A1+T, Automotive AEC-Q100, 1Kbit EEPROM, 1-Wire interface, 2 µs access time, 256 x 4 organization, -40°C to 125°C, 6-TSOC package, Surface Mount.
View Availability & Specs
LT3755EMSE-1#WPBF
Analog Devices LT3755EMSE-1#WPBF, DC DC Controller, Automotive AEC-Q100, Dimming Analog/PWM, Topology Flyback/SEPIC/Buck/Boost, Frequency 100kHz~1MHz, 1 Output, No Internal Switch, Supply 4.5V~40V, -40°C~125°C, 16-MSOP-EP.
View Availability & Specs
LT8301IS5#WTRMPBF
42VIN UP NO-OPTO ISO FLY CONV W/
View Availability & Specs
LT8301JS5#WTRMPBF
42VIN UP NO-OPTO ISO FLY CONV W/
View Availability & Specs
LT8336EV#WPBF
40V, 2.5A LOW IQ SYNC STEP-UP SI
View Availability & Specs
LT8338EMSE#PBF
IC REG BOOST ADJ 1.2A 10MSOP
View Availability & Specs

Technical Details & Description

Dual-output automotive buck for ECU rails

The MAX20019ATBA/V+T is a dual-channel step-down (buck) switching regulator. It delivers two fixed output voltages — 3.3 V on one channel and 1.8 V on the other — each rated for 500 mA continuous output current. The part operates from a 3.5 V to 17 V input bus.

Switching frequency and external component sizing

The 3.2 MHz switching frequency is fixed; there is no SYNC pin for external clock synchronisation. The part does not include internal synchronous rectification — an external Schottky diode per channel is required in the BOM.

Frequently asked questions

Does MAX20019ATBA/V+T have synchronous rectification?

No. Synchronous rectification is not implemented, so an external Schottky diode is required per output channel for the low-side rectifier function.

What is the output current of MAX20019ATBA/V+T?

Each of the two outputs is rated for 500 mA continuous current, providing a combined 1 A total output capability from the dual channels.
