Analog Devices ADG5401FBCPZ-RL7
MPNADG5401FBCPZ-RL7
End of Life
60V OV PROTECTED HV SPSTX1 SWITC
$14.99700Price · pay online now
$15.00 / ea
5 in stock — maximum per order · 3–4 days lead time
Packaging10-WFDFN, CSP
RoHSROHS3 Compliant
Independent supplier — new & surplus stockAuthenticity-screened · ESD-safe packingListing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Mounting | Surface Mount |
| Voltage - supply, dual (V±) | ±5V ~ 22V |
| Voltage - supply, single (V+) | 8V ~ 44V |
| Current - leakage (IS(off)) | 100pA (Typ) |
| Operating temperature | -40°C ~ 125°C |
| -3db bandwidth | 395MHz |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Case | 10-WFDFN, CSP |
| Switch circuit | SPST - NC |
| Charge injection | -230pC |
| Number of circuits | 1 |
| On-State resistance | 6Ohm (Typ) |
| Switch time (Ton, toff) | 10.2µs, 360ns |
| Multiplexer (Demultiplexer circuit) | 1:1 |
| Channel capacitance (CS(off), CD(off)) | 9pF, 11pF |
