TPS60130PWPR
Texas Instruments
Tape & Reel (TR); Cut Tape (CT)-40°C ~ 125°C (TJ)Step-Up
Ref. price$2.66
Lead time on requestGet quote
Texas Instruments TPS6 Discrete Semiconductors Series
10 variants · Texas Instruments
About the Texas Instruments TPS6 Discrete Semiconductors Series
The Texas Instruments TPS6 Discrete Semiconductors Series series groups 10 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common mounting of Surface Mount. Variants differ by case, package and function, so you can match the exact case your application requires using the selection guide below. All listed Texas Instruments TPS6 Discrete Semiconductors Series part numbers are active and orderable.
Select a variant by
- Case
- 6-WDFN Exposed Pad · 10-TFSOP, 10-MSOP (0.118\", 3.00mm Width) · 15-UFBGA, DSBGA · 20-PowerTSSOP (0.173\", 4.40mm Width) · 28-VFQFN Exposed Pad · 28-XFBGA, DSBGA
- Package
- Tape & Reel (TR); Cut Tape (CT) · Tube
- Function
- Buffer, Shifter · Ratiometric, Step-Up · Step-Up
- Operating temperature
- -40°C ~ 85°C · -40°C ~ 85°C (TA) · -40°C ~ 125°C (TJ) · -10°C ~ 85°C (TA)
- Frequency
- 1.5MHz · 320kHz · 700kHz
- I/O channels
- 1 · 2
- Output current
- 40mA, 20mA · 140mA · 150mA · 200mA · 300mA
- Voltage - input
- 1.8V · 3.6V · 5.4V · 5.5V
Shared specifications
- Mounting
- Surface Mount
Variant comparison
| Parameter | TPS60120PWPR | TPS60130PWPR | TPS60133PWP | TPS60151DRVR | TPS60300DGS | TPS60302DGS |
|---|---|---|---|---|---|---|
| Case | 20-PowerTSSOP (0.173\", 4.40mm Width) | 20-PowerTSSOP (0.173\", 4.40mm Width) | 20-PowerTSSOP (0.173\", 4.40mm Width) | 6-WDFN Exposed Pad | 10-TFSOP, 10-MSOP (0.118\", 3.00mm Width) | 10-TFSOP, 10-MSOP (0.118\", 3.00mm Width) |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tube | Tape & Reel (TR); Cut Tape (CT) | Tube | Tube |
| Function | Step-Up | Step-Up | Step-Up | Step-Up | Ratiometric, Step-Up | Ratiometric, Step-Up |
| Operating temperature | -40°C ~ 85°C (TA) | -40°C ~ 125°C (TJ) | — | -40°C ~ 85°C (TA) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) |
| Frequency | 320kHz | 320kHz | 320kHz | 1.5MHz | 700kHz | 700kHz |
| I/O channels | 1 | 1 | 1 | 1 | 2 | 2 |
| Output current | 200mA | 300mA | 150mA | 140mA | 40mA, 20mA | 40mA, 20mA |
| Voltage - input | 3.6V | 5.4V | 5.4V | 5.5V | 1.8V | 1.8V |
Request a quote on any Texas Instruments TPS6 Discrete Semiconductors Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
