Texas Instruments TPS7B8601DQDDARQ1 — Discrete Semiconductors
Texas Instruments

TPS7B8601DQDDARQ1 LDO, 500 mA, 40 Vin, AEC-Q100

MPNTPS7B8601DQDDARQ1
End of Life

Texas Instruments TPS7B8601DQDDARQ1 automotive LDO, adjustable output, 500 mA, 40 V input, 70 dB PSRR at 1 kHz, 8-PowerSOIC PowerPad, AEC-Q100.

$1.65Ref. price · indicative, final on quote
TPS7B8601DQDDARQ1 datasheet
Packaging8-PowerSOIC (0.154", 3.90mm Width)
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • 100% new & originalTraceable channels only — no refurbs, no pulls, no remarked parts.
  • Date & lot codes on quoteStated per line before you commit; label photos on request.
  • MSL-compliant ESD packingMoisture-sealed bags with indicator cards; reels photo-verified.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

TPS7B8601DQDDARQ1 Technical Specifications
ParameterValue
SeriesAutomotive, AEC-Q100
Output typeAdjustable
Mounting typeSurface Mount
Voltage - input40V
Voltage dropout0.570V @ 500mA
Voltage - output18V
Voltage - output (Min (Fixed))1.2V
Current - output500mA
Current - quiescent26 µA
Operating temperature-40°C ~ 125°C (TA)
PSRR70dB (1kHz)
PackageBulk
Case8-PowerSOIC (0.154\", 3.90mm Width)
Control featuresCurrent Limit, Delay, Enable, Power Good
Protection featuresOver Current, Over Temperature, Under Voltage Lockout (UVLO)
Number of regulators1
Output configurationPositive

Product details

Automotive LDO for noise-sensitive supply rails

The TPS7B8601DQDDARQ1 is an adjustable-output low-dropout linear regulator from Texas Instruments, part of the Automotive, AEC-Q100 series. It delivers up to 500 mA from a 40 V maximum input, making it suited for directly regulating battery voltage in automotive body electronics, infotainment, and ADAS sensor modules. With a 70 dB PSRR at 1 kHz, this LDO attenuates ripple from upstream switching converters or alternator noise, keeping the downstream analog or RF supply clean. The 26 µA quiescent current keeps the regulator's own draw low on always-on battery lines.

Wide input range and thermal package

The input voltage range extends to 40 V, covering automotive cold-crank dips and load-dump transients without an external clamp. The adjustable output is set between 1.2 V and 18 V via an external resistor divider. The 8-PowerSOIC package with an exposed PowerPad (8-SO PowerPad) pulls heat into the PCB copper plane. The 0.570 V maximum dropout at 500 mA means the input-to-output headroom must stay above that threshold to maintain regulation at full load. Operating temperature spans -40°C to 125°C ambient, matching the AEC-Q100 Grade 1 automotive qualification. Protection features include overcurrent, overtemperature, and undervoltage lockout (UVLO).

Active lifecycle and sourcing posture

Texas Instruments lists the TPS7B8601DQDDARQ1 as Active, with ROHS3 compliance.

Frequently asked questions

What is the PSRR of TPS7B8601DQDDARQ1?

The PSRR is 70 dB at 1 kHz, which means it attenuates ripple at that frequency by a factor of about 3160, keeping the output clean for noise-sensitive analog or RF loads.

Can TPS7B8601DQDDARQ1 replace TPS70612DBVT?

No, the TPS70612DBVT is a fixed 1.2 V output LDO with a 150 mA rating and 6.5 V maximum input. The TPS7B8601DQDDARQ1 is adjustable, handles 500 mA, and accepts up to 40 V input, so the two are not pin-compatible or drop-in replacements. A board-level redesign would be needed.
