L7805ABD2T-TR
STMicroelectronics
Tape & Reel (TR) Cut Tape (CT)-40°C ~ 125°C68dB (120Hz)
Ref. price$1.0600
Lead time on requestGet quote ›
STMicroelectronics L780 Series
30 variants · STMicroelectronics
About the STMicroelectronics STMicroelectronics L780 Series series
The STMicroelectronics STMicroelectronics L780 Series series groups 30 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common control features of -, current - output of 1.5A and number of regulators of 1. Variants differ by case, current - quiescent and mounting type, so you can match the exact case your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current STMicroelectronics L780 Series variants and discontinued ones from a single page.
Select a variant by
- Case
- TO-220-3 · TO-220-3 Full Pack · TO-252-3, DPak (2 Leads + Tab), SC-63 · TO-263-3, D2PAK (2 Leads + Tab), TO-263AB · TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Current - quiescent
- 6 mA · 8 mA
- Mounting type
- Surface Mount · Through Hole
- Operating temperature
- -40°C ~ 125°C · -40°C~125°C · 0°C ~ 125°C · 0°C~125°C
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT) · Tube
- PSRR
- 62dB (120Hz) · 68dB (120Hz)
Variant comparison
| Parameter | L7805ABD2T-TR | L7805ABP | L7805ABV | L7805ABV-DG | L7805ACD2T-TR | L7805ACP |
|---|---|---|---|---|---|---|
| Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | TO-220-3 Full Pack | TO-220-3 | TO-220-3 | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | TO-220-3 Full Pack |
| Current - quiescent | 6 mA | 6 mA | 6 mA | 6 mA | 6 mA | 6 mA |
| Mounting type | Surface Mount | Through Hole | Through Hole | Through Hole | Surface Mount | Through Hole |
| Operating temperature | -40°C ~ 125°C | -40°C~125°C | -40°C~125°C | -40°C ~ 125°C | 0°C ~ 125°C | 0°C ~ 125°C |
| Package | Tape & Reel (TR) Cut Tape (CT) | Tube | Tube | Tube | Tape & Reel (TR) Cut Tape (CT) | Tube |
| PSRR | 68dB (120Hz) | 68dB (120Hz) | 68dB (120Hz) | 68dB (120Hz) | 68dB (120Hz) | 68dB (120Hz) |
Shared specifications
- Control features
- -
- Current - output
- 1.5A
- Number of regulators
- 1
- Output configuration
- Positive
- Output type
- Fixed
- Protection features
- Over Temperature, Short Circuit
- Voltage - input
- 35V
- Voltage - output
- -
- Voltage - output (Min (Fixed))
- 5V
- Voltage dropout
- 2V @ 1A (Typ)
Request a quote on any STMicroelectronics L780 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the STMicroelectronics STMicroelectronics L780 Series variants differ?
- STMicroelectronics L780 Series part numbers differ by case, current - quiescent, mounting type and operating temperature. Use the selection guide above to pick by case.
- How many STMicroelectronics STMicroelectronics L780 Series part numbers are listed?
- 30 STMicroelectronics STMicroelectronics L780 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for STMicroelectronics STMicroelectronics L780 Series?
- Request a quote (RFQ) for any STMicroelectronics L780 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
