MK20DN128VLH5
NXP USA Inc.
Tray-40°C ~ 105°C (TA)50MHz
Ref. price$9.3200
Lead time on requestGet quote ›
NXP Semiconductors MK20DN Series
10 variants · NXP Semiconductors
About the NXP Semiconductors NXP Semiconductors MK20DN Series series
The NXP Semiconductors NXP Semiconductors MK20DN Series series groups 10 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common core processor of ARM® Cortex®-M4, core size of 32-Bit Single-Core and mounting type of Surface Mount. Variants differ by case, connectivity and data converters, so you can match the exact case your application requires using the selection guide below. All listed NXP Semiconductors MK20DN Series part numbers are active and orderable.
Select a variant by
- Case
- 48-LQFP · 48-VFQFN Exposed Pad · 64-LFBGA · 64-LQFP · 80-LQFP · 100-LQFP · 121-LFBGA
- Connectivity
- CANbus, EBI/EMI, I²C, IrDA, SD, SPI, UART/USART, USB, USB OTG · I²C, IrDA, SPI, UART/USART, USB, USB OTG
- Data converters
- A/D 11x16b · A/D 13x16b · A/D 27x16b; D/A 1x12b · A/D 33x16b; D/A 1x12b · A/D 38x16b; D/A 2x12b
- Number of i (O)
- 29 · 40 · 52 · 66
- Operating temperature
- -40°C ~ 105°C (TA) · -40°C~105°C(TA)
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tray
- Program memory size
- 32KB (32K x 8) · 64KB (64K x 8) · 128KB (128K x 8) · 512KB (512K x 8)
- RAM size
- 8K x 8 · 16K x 8 · 128K x 8
Variant comparison
| Parameter | MK20DN128VLH5 | MK20DN32VLH5 | MK20DN32VMP5 | MK20DN512VLK10 | MK20DN512VLK10R | MK20DN512VLL10 |
|---|---|---|---|---|---|---|
| Case | 64-LQFP | 64-LQFP | 64-LFBGA | 80-LQFP | 80-LQFP | 100-LQFP |
| Connectivity | I²C, IrDA, SPI, UART/USART, USB, USB OTG | I²C, IrDA, SPI, UART/USART, USB, USB OTG | I²C, IrDA, SPI, UART/USART, USB, USB OTG | CANbus, EBI/EMI, I²C, IrDA, SD, SPI, UART/USART, USB, USB OTG | CANbus, EBI/EMI, I²C, IrDA, SD, SPI, UART/USART, USB, USB OTG | CANbus, EBI/EMI, I²C, IrDA, SD, SPI, UART/USART, USB, USB OTG |
| Data converters | A/D 13x16b | A/D 13x16b | A/D 13x16b | A/D 27x16b; D/A 1x12b | A/D 27x16b; D/A 1x12b | A/D 33x16b; D/A 1x12b |
| Number of i (O) | 40 | 40 | 40 | 52 | 52 | 66 |
| Operating temperature | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) |
| Package | Tray | Tray | Tray | Tray | Tape & Reel (TR) Cut Tape (CT) | Tray |
| Program memory size | 128KB (128K x 8) | 32KB (32K x 8) | 32KB (32K x 8) | 512KB (512K x 8) | 512KB (512K x 8) | 512KB (512K x 8) |
| RAM size | 16K x 8 | 8K x 8 | 8K x 8 | 128K x 8 | 128K x 8 | 128K x 8 |
Shared specifications
- Core processor
- ARM® Cortex®-M4
- Core size
- 32-Bit Single-Core
- Mounting type
- Surface Mount
- Oscillator type
- Internal
- Peripherals
- DMA, I²S, LVD, POR, PWM, WDT
- Program memory type
- FLASH
- Voltage - supply (Vcc (Vdd))
- 1.71V ~ 3.6V
