MK20DX256VLQ10
NXP USA Inc.
Tray-40°C ~ 105°C (TA)100MHz
Ref. price$17.7800
Lead time on requestGet quote ›
NXP Semiconductors MK20 Series
7 variants · NXP Semiconductors
About the NXP Semiconductors NXP Semiconductors MK20 Series series
The NXP Semiconductors NXP Semiconductors MK20 Series series groups 7 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common core processor of ARM® Cortex®-M4, core size of 32-Bit Single-Core and mounting type of Surface Mount. Variants differ by case, connectivity and data converters, so you can match the exact case your application requires using the selection guide below. All listed NXP Semiconductors MK20 Series part numbers are active and orderable.
Select a variant by
- Case
- 48-VFQFN Exposed Pad · 64-LFBGA · 64-LQFP · 144-LBGA · 144-LQFP
- Connectivity
- CANbus, EBI/EMI, I²C, IrDA, SD, SPI, UART/USART, USB, USB OTG · I²C, IrDA, SPI, UART/USART, USB, USB OTG
- Data converters
- A/D 11x16b · A/D 13x16b · A/D 42x16b; D/A 2x12b · A/D 58x16b; D/A 2x12b
- EEPROM size
- 2K x 8 · 4K x 8 · 16K x 8
- Number of i (O)
- 29 · 40 · 100
- Operating temperature
- -40°C ~ 105°C (TA) · -40°C~105°C(TA)
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tray
- Program memory size
- 32KB (32K x 8) · 64KB (64K x 8) · 256KB (256K x 8) · 512KB (512K x 8)
Variant comparison
| Parameter | MK20DX256VLQ10 | MK20DX256VLQ10R | MK20DX32VLH5 | MK20DX32VMP5 | MK20DX64VFT5 | MK20DX64VMP5 |
|---|---|---|---|---|---|---|
| Case | 144-LQFP | 144-LQFP | 64-LQFP | 64-LFBGA | 48-VFQFN Exposed Pad | 64-LFBGA |
| Connectivity | CANbus, EBI/EMI, I²C, IrDA, SD, SPI, UART/USART, USB, USB OTG | CANbus, EBI/EMI, I²C, IrDA, SD, SPI, UART/USART, USB, USB OTG | I²C, IrDA, SPI, UART/USART, USB, USB OTG | I²C, IrDA, SPI, UART/USART, USB, USB OTG | I²C, IrDA, SPI, UART/USART, USB, USB OTG | I²C, IrDA, SPI, UART/USART, USB, USB OTG |
| Data converters | A/D 42x16b; D/A 2x12b | A/D 42x16b; D/A 2x12b | A/D 13x16b | A/D 13x16b | A/D 11x16b | A/D 13x16b |
| EEPROM size | 4K x 8 | 4K x 8 | 2K x 8 | 2K x 8 | 2K x 8 | 2K x 8 |
| Number of i (O) | 100 | 100 | 40 | 40 | 29 | 40 |
| Operating temperature | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C~105°C(TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) |
| Package | Tray | Tape & Reel (TR) Cut Tape (CT) | Tray | Tray | Tray | Tray |
| Program memory size | 256KB (256K x 8) | 256KB (256K x 8) | 32KB (32K x 8) | 32KB (32K x 8) | 64KB (64K x 8) | 64KB (64K x 8) |
Shared specifications
- Core processor
- ARM® Cortex®-M4
- Core size
- 32-Bit Single-Core
- Mounting type
- Surface Mount
- Oscillator type
- Internal
- Peripherals
- DMA, I²S, LVD, POR, PWM, WDT
- Program memory type
- FLASH
- Voltage - supply (Vcc (Vdd))
- 1.71V ~ 3.6V
Request a quote on any NXP Semiconductors MK20 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
