PIC18F47K42-E/P
Microchip Technology
2.3V ~ 5.5VTube-40°C~125°C(TA)
Ref. price$4.1500
Lead time on requestGet quote ›
Microchip Technology PIC18F Series
328 variants · Microchip Technology
About the Microchip Technology Microchip Technology PIC18F Series series
The Microchip Technology Microchip Technology PIC18F Series series groups 328 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common core processor of PIC, core size of 8-Bit and oscillator type of Internal. Variants differ by case, connectivity and data converters, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 14-SOIC (0.154\", 3.90mm Width) · 14-TSSOP (0.173\", 4.40mm Width) · 18-DIP (0.300\", 7.62mm) · 18-SOIC (0.295\", 7.50mm Width)
- Connectivity
- I2C, LINbus, SPI, UART/USART · I²C, LINbus, SPI, UART/USART · UART/USART
- Data converters
- A/D 1x12b; D/A 2x8b · A/D 7x10b · A/D 11x12b; D/A 2x8b
- EEPROM size
- 256 x 8 · 512 x 8
- Mounting type
- Surface Mount · Through Hole
- Number of i (O)
- 12 · 16
- Operating temperature
- -40°C ~ 85°C (TA) · -40°C ~ 125°C (TA) · -40°C~85°C(TA) · -40°C~125°C(TA)
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tube
Variant comparison
| Parameter | PIC18F04Q40-E/SL | PIC18F04Q41T-I/ST | PIC18F05Q41-E/ST | PIC18F05Q41-I/SL | PIC18F05Q41T-I/SL | PIC18F05Q41T-I/ST |
|---|---|---|---|---|---|---|
| Case | 14-SOIC (0.154\", 3.90mm Width) | 14-TSSOP (0.173\", 4.40mm Width) | 14-TSSOP (0.173\", 4.40mm Width) | 14-SOIC (0.154\", 3.90mm Width) | 14-SOIC (0.154\", 3.90mm Width) | 14-TSSOP (0.173\", 4.40mm Width) |
| Connectivity | I2C, LINbus, SPI, UART/USART | I2C, LINbus, SPI, UART/USART | I2C, LINbus, SPI, UART/USART | I²C, LINbus, SPI, UART/USART | I2C, LINbus, SPI, UART/USART | I2C, LINbus, SPI, UART/USART |
| Data converters | A/D 1x12b; D/A 2x8b | A/D 11x12b; D/A 2x8b | A/D 11x12b; D/A 2x8b | A/D 11x12b; D/A 2x8b | A/D 11x12b; D/A 2x8b | A/D 11x12b; D/A 2x8b |
| EEPROM size | 512 x 8 | 512 x 8 | 512 x 8 | 512 x 8 | 512 x 8 | 512 x 8 |
| Mounting type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Number of i (O) | 12 | 12 | 12 | 12 | 12 | 12 |
| Operating temperature | -40°C ~ 125°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 125°C (TA) | -40°C~85°C(TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Package | Tube | Tape & Reel (TR) Cut Tape (CT) | Tube | Tube | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) |
Shared specifications
- Core processor
- PIC
- Core size
- 8-Bit
- Oscillator type
- Internal
- Program memory type
- FLASH
Request a quote on any Microchip Technology PIC18F Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Microchip Technology Microchip Technology PIC18F Series variants differ?
- Microchip Technology PIC18F Series part numbers differ by case, connectivity, data converters and EEPROM size. Use the selection guide above to pick by case.
- How many Microchip Technology Microchip Technology PIC18F Series part numbers are listed?
- 328 Microchip Technology Microchip Technology PIC18F Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Microchip Technology Microchip Technology PIC18F Series?
- Request a quote (RFQ) for any Microchip Technology PIC18F Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
