BTS409L1E3062AAUMA1
Infineon Technologies
-40°C ~ 150°C (TJ)Auto Restart, Slew Rate ControlledTape & Reel (TR) Cut Tape (CT)
Ref. price$3.1900
Lead time on requestGet quote ›
Infineon Technologies BTS4 Series
17 variants · Infineon Technologies
About the Infineon Technologies Infineon Technologies BTS4 Series series
The Infineon Technologies Infineon Technologies BTS4 Series series groups 17 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common interface of On/Off, output configuration of High Side and output type of N-Channel. Variants differ by current - output, fault protection and features, so you can match the exact current - output your application requires using the selection guide below. All listed Infineon Technologies BTS4 Series part numbers are active and orderable.
Select a variant by
- Current - output
- 1.3A · 1.4A · 1.5A · 1.7A · 2.1A · 2.3A · 5.8A · 8.8A · 17A · 200mA · 400mA · 700mA
- Fault protection
- Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage · Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage, Reverse Current, Short Circuit · Current Limiting (Fixed), Over Temperature, Over Voltage · Current Limiting, Open Load Detect, Over Temperature, Over Voltage, UVLO
- Features
- - · Auto Restart · Auto Restart, Slew Rate Controlled · Status Flag
- Input type
- - · Non-Inverting
- Number of outputs
- 1 · 2 · 4
- Operating temperature
- -40°C ~ 125°C (TJ) · -40°C ~ 150°C (TJ)
- Rds on
- 1Ohm · 15mOhm · 35mOhm · 50mOhm · 130mOhm · 150mOhm · 160mOhm · 175mOhm · 200mOhm · 300mOhm
Variant comparison
| Parameter | BTS409L1E3062AAUMA1 | BTS40K21ENCXUMA1 | BTS4130QGAXUMA1 | BTS4140NHUMA1 | BTS4141NHUMA1 | BTS4142NHUMA1 |
|---|---|---|---|---|---|---|
| Current - output | 2.3A | 1.5A | 2.1A | 200mA | 700mA | 1.4A |
| Fault protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage, Reverse Current, Short Circuit | Current Limiting, Open Load Detect, Over Temperature, Over Voltage, UVLO | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage | Current Limiting (Fixed), Over Temperature, Over Voltage | Current Limiting (Fixed), Over Temperature, Over Voltage | Current Limiting (Fixed), Over Temperature, Over Voltage |
| Features | Auto Restart, Slew Rate Controlled | - | Status Flag | Auto Restart | Auto Restart | Auto Restart |
| Input type | Non-Inverting | - | Non-Inverting | Non-Inverting | Non-Inverting | Non-Inverting |
| Number of outputs | 1 | 1 | 4 | 1 | 1 | 1 |
| Operating temperature | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) |
| Rds on | 160mOhm | 200mOhm | 130mOhm | 1Ohm | 150mOhm | 150mOhm |
Shared specifications
- Interface
- On/Off
- Output configuration
- High Side
- Output type
- N-Channel
- Package
- Tape & Reel (TR) Cut Tape (CT)
- Ratio - Input:Output
- 1:1
- Switch type
- General Purpose
- Voltage - supply (Vcc (Vdd))
- Not Required
Request a quote on any Infineon Technologies BTS4 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Infineon Technologies Infineon Technologies BTS4 Series variants differ?
- Infineon Technologies BTS4 Series part numbers differ by current - output, fault protection, features and input type. Use the selection guide above to pick by current - output.
- How many Infineon Technologies Infineon Technologies BTS4 Series part numbers are listed?
- 17 Infineon Technologies Infineon Technologies BTS4 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Infineon Technologies Infineon Technologies BTS4 Series?
- Request a quote (RFQ) for any Infineon Technologies BTS4 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
