EPC — Analog & Data Acquisition

EPC Analog & Data Acquisition — 4 part numbers with specifications and datasheets. Filter by key specs and request a quote on ICBOMS.

Current - Continuous Drain (Id) @ 25°C
1.7A (Ta) · 1.7A, 500mA · 16A (Ta)
Drain to Source Voltage (Vdss)
100 V · 100V · 30V
Gate Charge (Qg) (Max) @ Vgs
2.1 nC @ 5 V · 0.16nC @ 5V, 0.044nC @ 5V · 2.2nC @ 5V, 5.7nC @ 5V
Input Capacitance (Ciss) (Max) @ Vds
258 pF @ 50 V · 16pF @ 50V, 7pF @ 50V · 230pF @ 15V, 590pF @ 15V
Package / Case
Die · 9-VFBGA · 12-WFLGA
Rds On (Max) @ Id, Vgs
25mOhm @ 3A, 5V · 320mOhm @ 2A, 5V, 3.3Ohm @ 2A, 5V · 19mOhm @ 15A, 5V, 8mOhm @ 15A, 5V
Supplier Device Package
Die · 9-BGA (1.35x1.35) · 12-LGA (3.85x2.59)
Vgs(th) (Max) @ Id
2.5V @ 1.5mA · 2.5V @ 100µA, 2.5V @ 20µA · 2.5V @ 5mA
