MAX6xx Voltage Reference and Power Management IC

178 variants · Analog DevicesAll Analog & Data Acquisition →

About the MAX6xx Voltage Reference and Power Management IC

The Analog Devices MAX6xx Voltage Reference and Power Management IC series groups 178 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting of Surface Mount. Variants differ by case, operating temperature and output type, so you can match the exact case your application requires using the selection guide below.

Select a variant by

Case: 8-SOIC (0.154\", 3.90mm Width) · 10-TFSOP, 10-MSOP (0.118\", 3.00mm Width) · TO-236-3, SC-59, SOT-23-3
Operating temperature: -40°C ~ 85°C (TA) · -40°C ~ 125°C
Output type: Fixed · I²C/SMBus
Package: Bulk · Tape & Reel (TR); Cut Tape (CT) · Tube
Noise - 0.1Hz to 10Hz: 12µVp-p · 25µVp-p · 30µVp-p · 60µVp-p · 100µVp-p · 120µVp-p
Output current: 2 mA · 7 mA · 400 µA · 500 µA
Reference type: Series · Shunt
Temperature coefficient: 20ppm/°C · 30ppm/°C · 50ppm/°C · 75ppm/°C · 100ppm/°C

Shared specifications

Mounting: Surface Mount

Variant comparison

Parameter	MAX6652AUB+T	MAX6001EUR+T	MAX6005EUR+T	MAX6006BESA+	MAX6006BEUR+T	MAX6007AEUR+T
Case	10-TFSOP, 10-MSOP (0.118\", 3.00mm Width)	TO-236-3, SC-59, SOT-23-3	TO-236-3, SC-59, SOT-23-3	8-SOIC (0.154\", 3.90mm Width)	TO-236-3, SC-59, SOT-23-3	TO-236-3, SC-59, SOT-23-3
Operating temperature	-40°C ~ 125°C	-40°C ~ 85°C (TA)	-40°C ~ 85°C (TA)	-40°C ~ 85°C (TA)	-40°C ~ 85°C (TA)	-40°C ~ 85°C (TA)
Output type	I²C/SMBus	Fixed	Fixed	Fixed	Fixed	Fixed
Package	Tape & Reel (TR); Cut Tape (CT)	Tape & Reel (TR); Cut Tape (CT)	Tape & Reel (TR); Cut Tape (CT)	Tube	Tape & Reel (TR); Cut Tape (CT)	Tape & Reel (TR); Cut Tape (CT)
Noise - 0.1Hz to 10Hz	—	25µVp-p	120µVp-p	30µVp-p	30µVp-p	60µVp-p
Output current	—	400 µA	400 µA	2 mA	2 mA	2 mA
Reference type	—	Series	Series	Shunt	Shunt	Shunt
Temperature coefficient	—	100ppm/°C	100ppm/°C	75ppm/°C	75ppm/°C	30ppm/°C

Request a quote on any MAX6xx Voltage Reference and Power Management IC part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
