LTC3409AEDD#PBF
Analog Devices
-40°C ~ 85°C (TA)Step-Down< 1 A
Ref. price$6.87
Lead time on requestGet quote
Analog Devices LTC3 Analog Series
25 variants · Analog Devices
About the Analog Devices LTC3 Analog Series
The Analog Devices LTC3 Analog Series series groups 25 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting of Surface Mount. Variants differ by case, operating temperature and package, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 6-WFDFN Exposed Pad · 8-WFDFN Exposed Pad · 10-TFSOP, 10-MSOP (0.118\", 3.00mm Width) · 10-TFSOP, 10-MSOP (0.118\", 3.00mm Width) Exposed Pad · 16-SSOP (0.154\", 3.90mm Width) · 16-WFDFN Exposed Pad · 16-WFQFN Exposed Pad · 20-WFQFN Exposed Pad · 32-WFQFN Exposed Pad · 36-FBGA
- Operating temperature
- -40°C ~ 85°C (TA) · -40°C ~ 85°C (TJ) · -40°C ~ 125°C · -40°C ~ 125°C (TJ)
- Package
- Bulk · Tape & Reel (TR); Cut Tape (CT) · Tray · Tube
- Frequency
- 1MHz · 1.7MHz ~ 2.6MHz · 2.25MHz · 20kHz ~ 1MHz · 50kHz ~ 1MHz · 70kHz ~ 700kHz · 200kHz ~ 400kHz · 250kHz ~ 530kHz · 250kHz ~ 750kHz · 255kHz ~ 530kHz · 850kHz
- I/O channels
- 1 · 2 · 4 · 9
- Topology
- Boost, Flyback, SEPIC · Buck · Buck-Boost · Cuk · Flyback, SEPIC, Step-Down (Buck), Step-Up (Boost) · Switched Capacitor (Charge Pump)
- Output configuration
- Negative · Positive · Positive, Isolation Capable
- Output type
- Adjustable · Transistor Driver
Shared specifications
- Mounting
- Surface Mount
Variant comparison
| Parameter | LTC3025IDC#TRPBF | LTC3219EUD#PBF | LTC3409AEDD#PBF | LTC3624IDD#PBF | LTC3644IY-2#PBF | LTC3704EMS#PBF |
|---|---|---|---|---|---|---|
| Case | 6-WFDFN Exposed Pad | 20-WFQFN Exposed Pad | 8-WFDFN Exposed Pad | 8-WFDFN Exposed Pad | 36-FBGA | 10-TFSOP, 10-MSOP (0.118\", 3.00mm Width) |
| Operating temperature | -40°C ~ 125°C | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 85°C (TA) |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tube | Tube | Tube | Tray | Tube |
| Frequency | — | 850kHz | 1.7MHz ~ 2.6MHz | 1MHz | 2.25MHz | 50kHz ~ 1MHz |
| I/O channels | — | 9 | 1 | 1 | 4 | 1 |
| Topology | — | Switched Capacitor (Charge Pump) | Buck | Buck | Buck | Cuk |
| Output configuration | Positive | — | Positive | Positive | Positive | Negative |
| Output type | Adjustable | — | Adjustable | Adjustable | Adjustable | Transistor Driver |
Request a quote on any Analog Devices LTC3 Analog Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
