Wolfspeed, Inc. — Logic ICs

Wolfspeed, Inc. Logic ICs — 18 part numbers with specifications and datasheets. Filter by key specs and request a quote on ICBOMS.

Gate Charge (Qg) (Max) @ Vgs
188 nC @ 15 V · 162 nC @ 15 V · 74 nC @ 15 V · 46 nC @ 15 V
Current - Continuous Drain (Id) @ 25°C
120A (Tc) · 100A (Tc) · 73A (Tc) · 36A (Tc)
Power Dissipation (Max)
416W (Tc) · 469W (Tc) · 240W (Tc) · 136W (Tc)
Input Capacitance (Ciss) (Max) @ Vds
5011 pF @ 400 V · 4818 pF @ 1000 V · 1503 pF @ 600 V · 1020 pF @ 600 V
Rds On (Max) @ Id, Vgs
21mOhm @ 55.8A, 15V · 28.8mOhm @ 50A, 15V · 39mOhm @ 35A, 15V · 79mOhm @ 13.2A, 15V
Vgs(th) (Max) @ Id
3.6V @ 15.5mA · 3.6V @ 17.7mA · 3.5V @ 11mA · 3.6V @ 5mA
Drain to Source Voltage (Vdss)
650 V · 1200 V · 900 V · 1000 V
Operating Temperature
-40°C ~ 175°C (TJ) · -40°C ~ 150°C (TJ) · -55°C ~ 150°C (TJ) · -55°C ~ 175°C (TJ)
