V30K45-M3/H
Vishay · TMBS® Series
DIODE SCHOTTKY 45V 30A FLATPAK
[IN STOCK] In Stock: 4 pcs
MOQ 1 · Tape & Reel (TR); Cut Tape (CT) · RoHS · EIA-481 · DAP/DDP · T/T
Technical specifications
| Parameter / Attribute | Specification / Value |
|---|---|
| Series | TMBS® |
| Diode type | Schottky |
| Mounting | Surface Mount |
| Voltage - DC reverse (Vr) | 45 V |
| Voltage - forward (Vf) (Max) @ if | 630 mV @ 30 A |
| Current - reverse leakage @ vr | 2 mA @ 45 V |
| Current - average rectified | 30A |
| Operating temperature - junction | -40°C ~ 150°C |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Case | 8-PowerTDFN |
| Capacitance @ vr, | 4000pF @ 4V, 1MHz |
V30K45-M3/H
[ALLOC] verified
