S3AFGHM3/I
Vishay · Automotive, AEC-Q101 Series
DIODE GEN PURP 400V 3A DO221AC
[IN STOCK] In Stock: 121 pcs
MOQ 1 · Tape & Reel (TR); Cut Tape (CT) · RoHS · EIA-481 · DAP/DDP · T/T
Technical specifications
| Parameter / Attribute | Specification / Value |
|---|---|
| Series | Automotive, AEC-Q101 |
| Diode type | Standard |
| Mounting | Surface Mount |
| Voltage - DC reverse (Vr) | 400 V |
| Voltage - forward (Vf) (Max) @ if | 1.1 V @ 3 A |
| Current - reverse leakage @ vr | 10 µA @ 400 V |
| Current - average rectified | 3A |
| Operating temperature - junction | -55°C ~ 175°C |
| Speed | Standard Recovery >500ns, > 200mA (Io) |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Case | DO-221AC, SMA Flat Leads |
| Capacitance @ vr, | 28pF @ 4V, 1MHz |
| Reverse recovery time | 2.7 µs |
