Toshiba Semiconductor TB6560AFTG,C8,EL
MPNTB6560AFTG,C8,EL
End of Life
STEPPING MOTOR DRIVER, 40V/3.5A,
$4.01Ref. price · indicative, final on quote
Packaging48-VFQFN Exposed Pad
RoHSROHS3 Compliant
Independent supplier — new & surplus stockAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Mounting | Surface Mount |
| Motor type - stepper | Bipolar |
| Voltage - load | 4.5V ~ 34V |
| Supply voltage | 4.5V ~ 5.5V |
| Output current | 2.5A |
| Interface | Parallel |
| Operating temperature | -30°C ~ 85°C (TA) |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Technology | Power MOSFET |
| Applications | General Purpose |
| Case | 48-VFQFN Exposed Pad |
| Step resolution | 1, 1/2, 1/4, 1/8, 1/16 |
| Output configuration | Half Bridge (4) |
