TPS54201DDCR
Texas Instruments
Tape & Reel (TR); Cut Tape (CT)-40°C ~ 125°C (TJ)DC DC Regulator
Ref. price$1.47
Lead time on requestGet quote
TPS5xxx Voltage Supervisors & Battery Chargers
17 variants · Texas Instruments
About the TPS5xxx Voltage Supervisors & Battery Chargers
The Texas Instruments TPS5xxx Voltage Supervisors & Battery Chargers series groups 17 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common I/O channels of 1, mounting of Surface Mount and package of Tape & Reel (TR); Cut Tape (CT). Variants differ by case, frequency and operating temperature, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 16-WFQFN Exposed Pad · 21-PowerVFQFN · 22-PowerLFDFN · 24-VFQFN Exposed Pad · 40-LFQFN Exposed Pad · SOT-23-6 Thin, TSOT-23-6
- Frequency
- 94kHz ~ 2.55MHz · 200kHz ~ 2.2MHz · 225kHz ~ 1.5MHz · 300kHz, 500kHz, 950kHz · 600kHz · 700kHz, 1MHz
- Operating temperature
- -40°C ~ 85°C (TA) · -40°C ~ 125°C (TA) · -40°C ~ 125°C (TJ) · -40°C ~ 150°C (TJ)
- Topology
- Boost · Buck · Buck-Boost
- Function
- Step-Down · Step-Up · Step-Up/Step-Down
- Output configuration
- Positive · Positive, Isolation Capable
- Output current
- 5.25A (Switch) · 6A · 6.35A (Switch) · 25A · 40A
- Output type
- Adjustable · Programmable
Shared specifications
- I/O channels
- 1
- Mounting
- Surface Mount
- Package
- Tape & Reel (TR); Cut Tape (CT)
Variant comparison
| Parameter | TPS51461RGET | TPS546D24SRVFR | TPS55340QRTETQ1 | TPS56221DQPR | TPS54201DDCR | TPS55289RYQR |
|---|---|---|---|---|---|---|
| Case | 24-VFQFN Exposed Pad | 40-LFQFN Exposed Pad | 16-WFQFN Exposed Pad | 22-PowerLFDFN | SOT-23-6 Thin, TSOT-23-6 | 21-PowerVFQFN |
| Frequency | 700kHz, 1MHz | 225kHz ~ 1.5MHz | 94kHz ~ 2.55MHz | 300kHz, 500kHz, 950kHz | 600kHz | 200kHz ~ 2.2MHz |
| Operating temperature | -40°C ~ 85°C (TA) | -40°C ~ 150°C (TJ) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) |
| Topology | Buck | Buck | Boost | Buck | Buck | Buck-Boost |
| Function | Step-Down | Step-Down | Step-Up | Step-Down | — | Step-Up/Step-Down |
| Output configuration | Positive | Positive | Positive, Isolation Capable | Positive | — | Positive |
| Output current | 6A | 40A | 5.25A (Switch) | 25A | — | 6.35A (Switch) |
| Output type | Programmable | Programmable | Adjustable | Adjustable | — | Adjustable |
Request a quote on any TPS5xxx Voltage Supervisors & Battery Chargers part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
