TMUX4052BQBRQ1
MPNTMUX4052BQBRQ1
End of Life
AUTOMOTIVE, 12-V, 4:1 TWO-CHANNE
$0.58Ref. price · indicative, final on quote
Packaging16-WFQFN Exposed Pad
RoHSROHS3 Compliant
Independent supplier — new & surplus stockAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Mounting | Surface Mount |
| Voltage - supply, single (V+) | 5V ~ 24V |
| Operating temperature | -55°C ~ 125°C (TA) |
| -3db bandwidth | 700MHz |
| Grade | Automotive |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Crosstalk | -90dB @ 1MHz |
| Qualification | AEC-Q100 |
| Case | 16-WFQFN Exposed Pad |
| Switch circuit | SP4T - Open |
| Number of circuits | 2 |
| On-State resistance | 240Ohm |
| Switch time (Ton, toff) | 110ns, 85ns (Typ) |
| Multiplexer (Demultiplexer circuit) | 4:1 |
| Channel-to-Channel matching (ΔRon) | 2Ohm |
| Channel capacitance (CS(off), CD(off)) | 3pF, 5pF |
