Texas Instruments TMUX1104DQAR
MPNTMUX1104DQAR
End of Life
IC SWITCH
$5.59488Price · pay online now
$5.59 / ea
1 in stock — maximum per order · 3–4 days lead time
Packaging10-UFDFN
RoHSROHS3 Compliant
Independent supplier — new & surplus stockAuthenticity-screened · ESD-safe packingListing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Mounting | Surface Mount |
| Voltage - supply, single (V+) | 1.08V ~ 5.5V |
| Current - leakage (IS(off)) | 80pA |
| Operating temperature | -40°C ~ 125°C (TA) |
| -3db bandwidth | 155MHz |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Crosstalk | -45dB @ 10MHz |
| Case | 10-UFDFN |
| Switch circuit | SP4T |
| Charge injection | 1.5pC |
| Number of circuits | 1 |
| On-State resistance | 4Ohm |
| Switch time (Ton, toff) | 12ns, 5ns (Typ) |
| Multiplexer (Demultiplexer circuit) | 4:1 |
| Channel capacitance (CS(off), CD(off)) | 6pF, 28pF |
| Channel-to-Channel matching (ΔRon) | 130mOhm |
