High-speed dual op-amp with 230 V/µs slew rate
Its 230 V/µs slew rate and 175 MHz -3 dB bandwidth suit it for video distribution, ADC drivers, and high-speed data acquisition where the signal must swing rail-to-rail quickly without slew-induced distortion. The two channels share a single 3.4 mA supply current, which keeps the power budget manageable in multichannel designs.
Supply range and thermal package
The 8-MSOP-PowerPad package includes an exposed thermal pad (the supplier device package is 8-MSOP-PowerPad) that helps pull heat out of the die when the amplifier is driving heavy loads or sustaining high slew rates. Each channel can deliver up to 85 mA of output current, enough to drive a 50 Ω back-terminated cable or a low-impedance ADC input.
Input offset and bias considerations
These numbers matter when the op-amp is used in precision DC-coupled paths; the offset will contribute a DC error at the output that may need trimming or software calibration in the ADC chain.
Temperature grade and deployment context
It belongs in controlled indoor equipment — lab instruments, bench-top test gear, video switchers, or telecom line cards inside a climate-controlled rack.
