Texas Instruments TCAN1043ADYYRQ1 — Interface & Transceivers

TCAN1043ADYYRQ1 CAN Transceiver, 8 Mbps, AEC-Q100, SOT-23-14

MPNTCAN1043ADYYRQ1
Active

Texas Instruments TCAN1043ADYYRQ1, Automotive AEC-Q100 CAN Transceiver, Half-Duplex, 8 Mbps, 4.5V–5.5V/40V Supply, SOT-23-14 Thin Package, -40°C to 150°C Junction.

$1.7100Ref. price · indicative, final on quote
Texas Instruments TCAN1043ADYYRQ1 datasheet (PDF)
Independent supplier — new & surplus stockAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

TCAN1043ADYYRQ1 specifications
ParameterValue
TypeTransceiver
SeriesAutomotive, AEC-Q100
MountingSurface Mount
Supply voltage4.5V ~ 5.5V, 4.5V ~ 40V
ProtocolCAN
Operating temperature-40°C~150°C(TJ)
DuplexHalf
PackageTape & Reel (TR); Cut Tape (CT)
Data rate8Mbps
CaseSOT-23-14 Thin, SOT-23 Variant
Receiver hysteresis140 mV
Number of drivers (Receivers)1/1

Product details

8 Mbps CAN FD transceiver for automotive networks

The device integrates a single driver and receiver, with receiver hysteresis of 140 mV for noise immunity on the bus. Supply voltage spans 4.5V to 5.5V on the VIO pin and 4.5V to 40V on the VBAT pin, allowing direct connection to a 12V or 24V battery system or a regulated 5V rail.

Housed in a 14-pin SOT-23 Thin variant (SOT-23-14), the TCAN1043ADYYRQ1 is a surface-mount device with a compact footprint suited for space-constrained ECU layouts. The supplier device package is 14-SOT-23-THIN. The thin profile helps with low-profile board stacking.

This is a production-grade part for new designs, not a phase-out or NRND device.

Frequently asked questions

Does TCAN1043ADYYRQ1 support CAN FD?

Yes, with a data rate of 8 Mbps, the TCAN1043ADYYRQ1 supports CAN FD (Flexible Data Rate) communication, enabling higher throughput for modern automotive networks.

Is TCAN1043ADYYRQ1 pin-compatible with TJA1043?

The TCAN1043ADYYRQ1 is a functional equivalent in the CAN transceiver space, but pin compatibility with the NXP TJA1043 should be verified against the respective datasheets. The TCAN1043A family from TI is designed as a drop-in replacement for the TJA1043 in many applications, but always confirm the pinout for your specific layout.
