LP8556TME-E03/NOPB LED Driver, DC-DC Boost Regulator

MPNLP8556TME-E03/NOPB
End of Life

Texas Instruments LP8556TME-E03/NOPB, DC-DC Step-Up (Boost) Regulator, 5 outputs, 20 mA per channel, 16V to 34.5V output, PWM dimming, 312kHz/625kHz/1250kHz switching frequency, 20-DSBGA package, -30°C to 85°C.

$2.16Ref. price · indicative, final on quote
LP8556TME-E03/NOPB datasheet
Packaging20-WFBGA, DSBGA
StockContact for availability
MOQ1 pcs
  • 100% new & originalTraceable channels only — no refurbs, no pulls, no remarked parts.
  • Date & lot codes on quoteStated per line before you commit; label photos on request.
  • MSL-compliant ESD packingMoisture-sealed bags with indicator cards; reels photo-verified.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

LP8556TME-E03/NOPB Technical Specifications
ParameterValue
TypeDC DC Regulator
Mounting typeSurface Mount
Voltage - output16V ~ 34.5V
Voltage2.7V
Current - output (Channel)20mA
Frequency312kHz, 625kHz, 1250kHz
Number of outputs5
Operating temperature-30°C ~ 85°C (TA)
DimmingPWM
PackageTape & Reel (TR); Cut Tape (CT)
TopologyStep-Up (Boost)
ApplicationsBacklight
Case20-WFBGA, DSBGA
Internal switchYes

Product details

Five-channel boost regulator for LED backlight panels

Housed in a 20-DSBGA package measuring 2.04 mm x 1.78 mm. Surface-mount part. Lead-free and ROHS3 compliant.

Switching frequency selection — inductor vs efficiency trade-off

Three switching frequencies: 312 kHz, 625 kHz, and 1250 kHz. Lower frequency reduces switching losses; higher frequency shrinks inductor footprint.

Sourcing and lifecycle

Active lifecycle status from Texas Instruments. No last-time-buy or end-of-life notice in effect. ROHS3 compliant.
