Dual LVDS serializer with AEC-Q100 qualification
The DS90C187LF/NOPB is a dual LVDS serializer from Texas Instruments, part of the Automotive, AEC-Q100 series. It converts 53 LVCMOS inputs into 8 FPD-Link LVDS outputs at a serial data rate of 5.57 Gbps.
Supply rails and package footprint
Operates from a single 1.71 V to 1.89 V supply rail, which aligns with standard 1.8 V core logic in automotive SoCs. The dual-row VFQFN footprint with 0.5 mm pitch requires a solder paste stencil with appropriate aperture ratio to avoid bridging between the inner and outer rows. The exposed pad also serves as the primary electrical ground return for the high-speed LVDS outputs.
Active lifecycle and compliance
ROHS3 compliant, with no exemptions for lead in solder — suitable for RoHS-regulated assemblies.
