STTH10R04B-TR
STMicroelectronics
Surface MountTape & Reel (TR) Cut Tape (CT)Fast Recovery =< 500ns, > 200mA (Io)
Lead time on requestGet quote
STTH Ultrafast Recovery Diode
485 variants · STMicroelectronics
About the STTH Ultrafast Recovery Diode
The STMicroelectronics STTH Ultrafast Recovery Diode series groups 485 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common package of Tube, speed of Fast Recovery =< 500ns, > 200mA (Io) and technology of Standard. Variants differ by case, current - average rectified (Io) (per diode) and current - reverse leakage @ vr, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- ISOTOP · TO-220-3
- Current - average rectified (Io) (per diode)
- 8A · 100A
- Current - reverse leakage @ vr
- 5 µA @ 200 V · 80 µA @ 400 V
- Diode configuration
- 1 Pair Common Cathode · 2 Independent
- Mounting
- Chassis Mount · Through Hole
- Operating temperature - junction
- -55°C ~ 150°C · 175°C (Max)
- Reverse recovery time
- 25 ns · 100 ns
- Voltage - DC reverse (Vr)
- 200 V · 400 V
Shared specifications
- Package
- Tube
- Speed
- Fast Recovery =< 500ns, > 200mA (Io)
- Technology
- Standard
Variant comparison
| Parameter | STTH1002CT | STTH200R04TV1 |
|---|---|---|
| Case | TO-220-3 | ISOTOP |
| Current - average rectified (Io) (per diode) | 8A | 100A |
| Current - reverse leakage @ vr | 5 µA @ 200 V | 80 µA @ 400 V |
| Diode configuration | 1 Pair Common Cathode | 2 Independent |
| Mounting | Through Hole | Chassis Mount |
| Operating temperature - junction | 175°C (Max) | -55°C ~ 150°C |
| Reverse recovery time | 25 ns | 100 ns |
| Voltage - DC reverse (Vr) | 200 V | 400 V |
Request a quote on any STTH Ultrafast Recovery Diode part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
