STMicroelectronics LM290 Series
43 variants · STMicroelectronics
About the STMicroelectronics STMicroelectronics LM290 Series series
The STMicroelectronics STMicroelectronics LM290 Series series groups 43 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common mounting type of Surface Mount. Variants differ by case, current - input bias and operating temperature, so you can match the exact case your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current STMicroelectronics LM290 Series variants and discontinued ones from a single page.
Select a variant by
- Case
- 8-SOIC (0.154\", 3.90mm Width) · 8-TSSOP (0.173\", 4.40mm Width) · 14-SOIC (0.154\", 3.90mm Width) · 14-TSSOP (0.173\", 4.40mm Width) · 16-VFQFN Exposed Pad
- Current - input bias
- - · 0.25µA @ 5V · 20 nA
- Operating temperature
- - · -40°C ~ 125°C · -40°C ~ 150°C · -40°C~125°C
- Output type
- - · CMOS, DTL, ECL, MOS, Open-Collector, TTL · CMOS, DTL, MOS, Open-Collector, TTL · CMOS, MOS, Open-Collector, TTL · Differential · Open-Collector, CMOS, DTL, ECL, MOS, TTL, - · Open-Collector, Rail-to-Rail · Push-Pull
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT) · Tube
- Voltage - input offset
- - · 2 mV · 7mV @ 5V · 7mV @ 30V
- Current - output
- - · 16mA @ 5V · 20mA
Variant comparison
| Parameter | LM2901D | LM2901Q4T | LM2901YDT | LM2901YPT | LM2902AWYDT | LM2902Q4T |
|---|---|---|---|---|---|---|
| Case | 14-SOIC (0.154\", 3.90mm Width) | 16-VFQFN Exposed Pad | 14-SOIC (0.154\", 3.90mm Width) | 14-TSSOP (0.173\", 4.40mm Width) | 14-SOIC (0.154\", 3.90mm Width) | 16-VFQFN Exposed Pad |
| Current - input bias | 0.25µA @ 5V | - | 0.25µA @ 5V | 0.25µA @ 5V | 20 nA | 20 nA |
| Operating temperature | -40°C~125°C | - | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C |
| Output type | CMOS, MOS, Open-Collector, TTL | CMOS, DTL, MOS, Open-Collector, TTL | CMOS, DTL, ECL, MOS, Open-Collector, TTL | CMOS, DTL, ECL, MOS, Open-Collector, TTL | Push-Pull | Push-Pull |
| Package | Tube | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) |
| Voltage - input offset | 7mV @ 30V | - | 7mV @ 5V | 7mV @ 5V | 2 mV | 2 mV |
| Current - output | 20mA | - | 16mA @ 5V | 16mA @ 5V | — | — |
Shared specifications
- Mounting type
- Surface Mount
Request a quote on any STMicroelectronics LM290 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the STMicroelectronics STMicroelectronics LM290 Series variants differ?
- STMicroelectronics LM290 Series part numbers differ by case, current - input bias, operating temperature and output type. Use the selection guide above to pick by case.
- How many STMicroelectronics STMicroelectronics LM290 Series part numbers are listed?
- 43 STMicroelectronics STMicroelectronics LM290 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for STMicroelectronics STMicroelectronics LM290 Series?
- Request a quote (RFQ) for any STMicroelectronics LM290 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
