STMicroelectronics STM8AL3146TAY, 8-bit STM8A MCU, 16 MHz, 16 KB Flash, 2K x 8 RAM, 1K x 8 EEPROM, 30 I/O, 22x12b ADC, 1x12b DAC, I²C/SPI/UART/LIN, 32-LQFP, -40 to 85°C.
$1.8074Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
- 100% new & originalTraceable channels only — no refurbs, no pulls, no remarked parts.
- Date & lot codes on quoteStated per line before you commit; label photos on request.
- MSL-compliant ESD packingMoisture-sealed bags with indicator cards; reels photo-verified.
- PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
Specifications
| Parameter | Value |
|---|---|
| Series | STM8A |
| Mounting type | Surface Mount |
| Oscillator type | Internal |
| Program memory type | FLASH |
| Voltage - supply (Vcc (Vdd)) | 1.65V ~ 3.6V |
| Operating temperature | -40°C ~ 85°C (TA) |
| Speed | 16MHz |
| Package | Tray |
| RAM size | 2K x 8 |
| Core size | 8-Bit |
| EEPROM size | 1K x 8 |
| Peripherals | Brown-out Detect/Reset, DMA, POR, PWM, WDT |
| Connectivity | I²C, IrDA, LINbus, SPI, UART/USART |
| Number of i (O) | 30 |
| Core processor | STM8 |
| Case | 32-LQFP |
| Data converters | A/D 22x12b; D/A 1x12b |
| Program memory size | 16KB (16K x 8) |
Frequently asked questions
What is the closest pin-compatible alternative to the STM8AL3146TAY?
ST does not publish an official pin-compatible replacement for the STM8AL3146TAY under its NRND status. The STM8A family includes higher-density siblings (e.g., 64 KB Flash variants) that share the same 32-LQFP footprint, but verify pin compatibility against the datasheet's ordering information before substituting.
What is the STM8AL3146TAY's core speed?
The STM8AL3146TAY runs at 16 MHz.
