STMicroelectronics STM32F4 series, ARM® Cortex®-M4 32-bit MCU, 100 MHz, 1 MB Flash, 320 KB RAM, 114 I/O, 144-UFBGA, -40°C to 85°C.
| Parameter | Value |
|---|---|
| Series | STM32F4 |
| Mounting | Surface Mount |
| Oscillator type | Internal |
| Program memory type | FLASH |
| Voltage - supply (Vcc (Vdd)) | 1.7V ~ 3.6V |
| Operating temperature | -40°C ~ 85°C (TA) |
| Speed | 100MHz |
| Package | Tray |
| RAM size | 320K x 8 |
| Core size | 32-Bit Single-Core |
| Peripherals | Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT |
| Connectivity | CANbus, EBI/EMI, I²C, IrDA, LINbus, MMC/SDIO, QSPI, SAI, SPI, UART/USART, USB OTG |
| Number of i (O) | 114 |
| Core processor | ARM® Cortex®-M4 |
| Case | 144-UFBGA |
| Data converters | A/D 16x12b; D/A 2x12b |
| Program memory size | 1MB (1M x 8) |
The 114 I/O lines and connectivity set — CAN, USB OTG, QSPI, SAI, and multiple UART/SPI/I²C — cover most industrial communication needs in one chip. The 16-channel 12-bit ADC and dual 12-bit DAC handle analog front-end tasks for sensor conditioning or closed-loop control.
The STM32F413ZGJ6 carries an end-of-life (hot) status.
Rated for -40°C to 85°C, this MCU operates from 1.7 V to 3.6 V.
We source the STM32F413ZGJ6 to order against an RFQ. Submit a request through our site or contact our sales team; we will confirm availability and provide a current price quote. No stock or price figures are published here because the market for EOL parts moves quickly.
The STM32F413ZGH6 and STM32F412ZGJ6 are pin-compatible alternatives in the same 144-UFBGA package and STM32F4 family. Verify Flash and RAM sizes, peripheral set, and any firmware changes needed before substituting.
The core runs at 100 MHz, which is the maximum clock for this Cortex-M4 device. That gives you roughly 125 DMIPS with DSP extensions and a floating-point unit for signal processing or control loops.
Lead time varies with market conditions for this EOL-hot part. We confirm lead time at quote time based on available inventory in our supply network. Contact us for a current estimate.
