Specifications
| Parameter | Value |
|---|---|
| Series | MDmesh™ II |
| FET type | N-Channel |
| Mounting type | Through Hole |
| Drain to source voltage | 650 V |
| Drive voltage (Max rds on, min rds on) | 10V |
| Current - continuous drain (Id) @ 25°C | 15A (Tc) |
| Power dissipation | 30W (Tc) |
| Operating temperature | 150°C (TJ) |
| Package | Tube |
| Vgs | ±25V |
| Technology | MOSFET (Metal Oxide) |
| Case | TO-262-3 Full Pack, I²Pak |
| Vgs(th) (Max) @ id | 4V @ 250µA |
| Rds on (Max) @ id, vgs | 270mOhm @ 7.5A, 10V |
| Gate charge (Qg) (Max) @ vgs | 44 nC @ 10 V |
| Input capacitance (Ciss) (Max) @ vds | 1280 pF @ 50 V |
