STMicroelectronics L7805ABP — Power Management (PMIC / Gate Driver)

STMicroelectronics L7805ABP Linear Regulator, 5V Fixed, 1.5A

MPNL7805ABP
Active

STMicroelectronics L7805ABP, 5V fixed positive linear voltage regulator, 1.5A output, 35V input max, 2V dropout at 1A, 68dB PSRR at 120Hz, TO-220-3 Full Pack, through hole, -40°C~125°C.

$1.5300Ref. price · indicative, final on quote
STMicroelectronics L7805ABP datasheet (PDF)
PackagingTO-220-3 Full Pack
RoHSROHS3 Compliant
Independent supplier — new & surplus stockAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

L7805ABP specifications
ParameterValue
Output typeFixed
MountingThrough Hole
Voltage - input35V
Voltage dropout2V @ 1A (Typ)
Voltage - output (Min (Fixed))5V
Output current1.5A
Current - quiescent6 mA
Operating temperature-40°C~125°C
PSRR68dB (120Hz)
PackageTube
CaseTO-220-3 Full Pack
Protection featuresOver Temperature, Short Circuit
Number of regulators1
Output configurationPositive

Product details

5V rail, 1.5A headroom — what this regulator delivers

The STMicroelectronics L7805ABP is a fixed 5V positive linear regulator rated for 1.5A continuous output. It takes an unregulated DC input up to 35V and drops it to a regulated 5V rail with a typical dropout of 2V at full load. The TO-220FP full-pack package isolates the tab electrically, so no insulating pad is needed when bolting to a chassis or heatsink — a time-saver in panel and power-supply builds.

Protection features and quiescent draw

Over-temperature shutdown and short-circuit protection are built in. Quiescent current is 6 mA.

Package and mounting — TO-220FP

The TO-220-3 Full Pack (TO-220FP) is a through-hole package with a fully insulated tab.

ROHS3 compliant. Pricing and availability are confirmed at quote time through independent distribution; submit an RFQ for the current market position.

Frequently asked questions

What is the output current capability of L7805ABP?

The L7805ABP is rated for 1.5 A continuous output current. Heatsinking is required for sustained loads near the maximum; the full-pack tab simplifies mounting.

Can I use L7805ABP as a replacement for L7805CV?

The L7805ABP is a pin-compatible functional equivalent to the L7805CV in the same TO-220 footprint, but the ABP uses the full-pack (TO-220FP) insulated tab, while the CV typically uses a standard TO-220 with a conductive tab. Verify the mechanical fit in your heatsink or chassis mount — the full-pack body is slightly thicker and the tab is fully isolated.

What is L7805ABP's PSRR specification?

The L7805ABP provides 68 dB ripple rejection at 120 Hz, which attenuates full-wave-rectifier ripple to sub-millivolt levels on the output for clean analog or digital rails.
