Renesas R7FA2E2A34CNK#AA1 RA2E2 MCU, 48MHz ARM Cortex-M23

MPNR7FA2E2A34CNK#AA1
End of Life

Renesas RA2E2 series, R7FA2E2A34CNK#AA1, 32-bit ARM Cortex-M23 MCU, 48MHz, 16KB Flash, 8KB RAM, 2KB EEPROM, 20 I/O, 24-HWQFN, -40 to 125°C, 1.6V to 5.5V.

$2.06Ref. price · indicative, final on quote
R7FA2E2A34CNK#AA1 datasheet
Packaging24-WFQFN Exposed Pad
StockContact for availability
MOQ1 pcs
  • 100% new & originalTraceable channels only — no refurbs, no pulls, no remarked parts.
  • Date & lot codes on quoteStated per line before you commit; label photos on request.
  • MSL-compliant ESD packingMoisture-sealed bags with indicator cards; reels photo-verified.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

R7FA2E2A34CNK#AA1 Technical Specifications
ParameterValue
SeriesRA2E2
Mounting typeSurface Mount
Oscillator typeExternal
Program memory typeFLASH
Voltage - supply (Vcc (Vdd))1.6V ~ 5.5V
Operating temperature-40°C ~ 125°C (TA)
Speed48MHz
PackageTray
RAM size8K x 8
Core size32-Bit
EEPROM size2K x 8
PeripheralsDMA, LVD, POR, PWM, WDT
ConnectivityI²C, SPI, UART/USART
Number of i (O)20
Core processorARM® Cortex®-M23
Case24-WFQFN Exposed Pad
Data convertersA/D 8x12b SAR
Program memory size16KB (16K x 8)

Product details

RA2E2 entry-level 32-bit MCU for sensor and control applications

The R7FA2E2A34CNK#AA1 is a 32-bit ARM Cortex-M23 MCU from the RA2E2 series, clocked at 48 MHz with 16 KB Flash and 8 KB SRAM. It includes 2 KB on-chip EEPROM and operates from -40°C to 125°C with a 1.6 V to 5.5 V supply. Peripherals include DMA, LVD, POR, PWM, and WDT, with connectivity covering I²C, SPI, and UART/USART. An 8-channel 12-bit SAR ADC handles analog inputs. The MCU comes in a 24-HWQFN exposed-pad package (4x4 mm), with 20 general-purpose I/O lines.

Memory footprint — sizing for the firmware load

16 KB Flash and 8 KB RAM place this MCU in the small-footprint tier. It is sized for a single control loop, a sensor-fusion algorithm, or a UART-to-I²C bridge. The 2 KB EEPROM stores calibration coefficients or fault logs.

Frequently asked questions

Is R7FA2E2A34CNK#AA1 obsolete?

No. The lifecycle status is Active with no end-of-life announcement. It is current-production and ROHS3 compliant.

Is R7FA2E2A34CNK#AA1 compatible with 5V logic?

Yes. The supply voltage range of 1.6 V to 5.5 V means the MCU can operate from a 5 V rail and its I/O levels track Vcc. At 5 V supply, the logic thresholds are 5 V compatible.

What is the difference between RA2E2 and RA2A1 series?

The RA2A1 series is a higher-tier family with larger memory options, more peripherals (including USB and CAN), and a wider operating temperature range. The RA2E2 is the entry-level, cost-optimized series with smaller Flash/RAM and a reduced peripheral set, targeted at simple sensor and control applications.

What is R7FA2E2A34CNK#AA1's listed speed?

The core runs at 48 MHz, which is the maximum clock for the RA2E2 series Cortex-M23 implementation.
