Specifications
| Parameter | Value |
|---|---|
| Series | EVQPL |
| Actuation | Standard |
| Mounting | Surface Mount |
| Contact rating @ voltage | 0.02A @ 15VDC |
| Operating temperature | -20°C ~ 70°C |
| Actuator height off PCB, vertical | 1.50mm |
| Mechanical life | 500,000 Cycles |
| Circuit | SPST-NO |
| Outline | 4.90mm x 4.90mm |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Push Plate |
| Illumination | Non-Illuminated |
| Switch travel | 0.25mm |
| Operating force | 102gf |
| Switch function | Off-Mom |
| Termination style | J Lead |
| Actuator orientation | Top Actuated |
