Specifications
| Parameter | Value |
|---|---|
| Series | EVQP4 |
| Actuation | Rectangular Button |
| Mounting | Edge Mount, Right Angle |
| Contact rating @ voltage | 0.02A @ 15VDC |
| Operating temperature | -40°C~85°C |
| Mechanical life | 1,000,000 Cycles |
| Circuit | SPST-NO |
| Outline | 6.20mm x 2.55mm |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Illumination | Non-Illuminated |
| Switch travel | 0.25mm |
| Operating force | 160gf |
| Switch function | Off-Mom |
| Termination style | SMD (SMT) Tab |
| Actuator orientation | Side Actuated |
| Actuator length, right angle | 2.10mm |
