SS13
onsemi
DIODE SCHOTTKY 30V 1A DO214AC
[IN STOCK] In Stock: 262 pcs
MOQ 1 · Tape & Reel (TR); Cut Tape (CT) · RoHS · EIA-481 · DAP/DDP · T/T
Technical specifications
| Parameter / Attribute | Specification / Value |
|---|---|
| Diode type | Schottky |
| Mounting | Surface Mount |
| Voltage - DC reverse (Vr) | 30 V |
| Voltage - forward (Vf) (Max) @ if | 500 mV @ 1 A |
| Current - reverse leakage @ vr | 200 µA @ 30 V |
| Current - average rectified | 1A |
| Operating temperature - junction | -65°C ~ 125°C |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Case | DO-214AC, SMA |
SS13
