PIC16F15223T-I/MG
Microchip Technology
1.8V ~ 5.5VTape & Reel (TR); Cut Tape (CT)-40°C~85°C(TA)
Ref. price$0.7200
Lead time on requestGet quote ›
Microchip Technology PIC16F Series
490 variants · Microchip Technology
About the Microchip Technology Microchip Technology PIC16F Series series
The Microchip Technology Microchip Technology PIC16F Series series groups 490 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common core processor of PIC, core size of 8-Bit and EEPROM size of -. Variants differ by case, connectivity and data converters, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 14-SOIC (0.154\", 3.90mm Width) · 16-UQFN Exposed Pad · 16-VFQFN Exposed Pad · 16-VQFN Exposed Pad · 20-SOIC (0.295\", 7.50mm Width) · 20-SSOP (0.209\", 5.30mm Width) · 20-VFQFN Exposed Pad
- Connectivity
- - · I2C, LINbus, SPI, UART/USART, USB · I²C, LINbus, SPI, UART/USART, USB · I²C, SPI
- Data converters
- - · A/D 5x10b; D/A 1x5b · A/D 8x10b · A/D 9x10b; D/A 1x5b · A/D 12x10b
- Number of i (O)
- 8 · 11 · 14 · 17
- Operating temperature
- -40°C ~ 85°C (TA) · -40°C~85°C(TA) · -40°C~125°C(TA)
- Package
- Tape & Reel (TR); Cut Tape (CT) · Tube
- Program memory size
- 3.5KB (2K x 14) · 14KB (8K x 14)
- RAM size
- 1K x 8 · 128 x 8
Variant comparison
| Parameter | PIC16F1454-I/JQ | PIC16F1454-I/ML | PIC16F1455-I/JQ | PIC16F1455-I/ML | PIC16F1455T-I/SL | PIC16F1459-I/ML |
|---|---|---|---|---|---|---|
| Case | 16-UQFN Exposed Pad | 16-VQFN Exposed Pad | 16-UQFN Exposed Pad | 16-VQFN Exposed Pad | 14-SOIC (0.154\", 3.90mm Width) | 20-VFQFN Exposed Pad |
| Connectivity | I²C, LINbus, SPI, UART/USART, USB | I2C, LINbus, SPI, UART/USART, USB | I²C, LINbus, SPI, UART/USART, USB | I²C, LINbus, SPI, UART/USART, USB | I²C, LINbus, SPI, UART/USART, USB | I²C, LINbus, SPI, UART/USART, USB |
| Data converters | - | - | A/D 5x10b; D/A 1x5b | A/D 5x10b; D/A 1x5b | A/D 5x10b; D/A 1x5b | A/D 9x10b; D/A 1x5b |
| Number of i (O) | 8 | 8 | 8 | 8 | 8 | 14 |
| Operating temperature | -40°C~85°C(TA) | -40°C ~ 85°C (TA) | -40°C~85°C(TA) | -40°C~85°C(TA) | -40°C~85°C(TA) | -40°C~85°C(TA) |
| Package | Tube | Tube | Tube | Tube | Tape & Reel (TR); Cut Tape (CT) | Tube |
| Program memory size | 14KB (8K x 14) | 14KB (8K x 14) | 14KB (8K x 14) | 14KB (8K x 14) | 14KB (8K x 14) | 14KB (8K x 14) |
| RAM size | 1K x 8 | 1K x 8 | 1K x 8 | 1K x 8 | 1K x 8 | 1K x 8 |
Shared specifications
- Core processor
- PIC
- Core size
- 8-Bit
- EEPROM size
- -
- Mounting type
- Surface Mount
- Oscillator type
- Internal
- Peripherals
- Brown-out Detect/Reset, POR, PWM, WDT
- Program memory type
- FLASH
- Voltage - supply (Vcc (Vdd))
- 2.3V ~ 5.5V
Request a quote on any Microchip Technology PIC16F Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Microchip Technology Microchip Technology PIC16F Series variants differ?
- Microchip Technology PIC16F Series part numbers differ by case, connectivity, data converters and number of i (O). Use the selection guide above to pick by case.
- How many Microchip Technology Microchip Technology PIC16F Series part numbers are listed?
- 490 Microchip Technology Microchip Technology PIC16F Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Microchip Technology Microchip Technology PIC16F Series?
- Request a quote (RFQ) for any Microchip Technology PIC16F Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
