PIC12F1501T-I/SN
Microchip Technology
2.3V ~ 5.5VTape & Reel (TR); Cut Tape (CT)-40°C~85°C(TA)
Ref. price$1.0200
Lead time on requestGet quote ›
Microchip Technology PIC12 Series
100 variants · Microchip Technology
About the Microchip Technology Microchip Technology PIC12 Series series
The Microchip Technology Microchip Technology PIC12 Series series groups 100 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common core processor of PIC, core size of 8-Bit and oscillator type of Internal. Variants differ by case, connectivity and data converters, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 8-DIP (0.300\", 7.62mm) · 8-SOIC (0.154\", 3.90mm Width) · 8-VDFN Exposed Pad · 8-VFDFN Exposed Pad
- Connectivity
- - · I²C, LINbus, SPI, UART/USART · LINbus, UART/USART
- Data converters
- - · A/D 4x10b · A/D 4x10b; D/A 1x5b
- EEPROM size
- - · 256 x 8
- Mounting type
- Surface Mount · Through Hole
- Number of i (O)
- 5 · 6
- Operating temperature
- -40°C ~ 85°C (TA) · -40°C ~ 125°C (TA) · -40°C~85°C(TA) · -40°C~125°C(TA)
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT) · Tube
Variant comparison
| Parameter | PIC12F1501T-I/SN | PIC12F1572-E/MF | PIC12F1572T-I/SN | PIC12F1612-E/SN | PIC12F1612-I/MF | PIC12F1612-I/P |
|---|---|---|---|---|---|---|
| Case | 8-SOIC (0.154\", 3.90mm Width) | 8-VDFN Exposed Pad | 8-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) | 8-VDFN Exposed Pad | 8-DIP (0.300\", 7.62mm) |
| Connectivity | - | LINbus, UART/USART | LINbus, UART/USART | - | - | - |
| Data converters | A/D 4x10b | A/D 4x10b; D/A 1x5b | A/D 4x10b; D/A 1x5b | A/D 4x10b | A/D 4x10b | A/D 4x10b |
| EEPROM size | - | - | - | - | - | - |
| Mounting type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Through Hole |
| Number of i (O) | 5 | 6 | 6 | 6 | 6 | 6 |
| Operating temperature | -40°C~85°C(TA) | -40°C~125°C(TA) | -40°C~85°C(TA) | -40°C~125°C(TA) | -40°C~85°C(TA) | -40°C~85°C(TA) |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tube | Tape & Reel (TR); Cut Tape (CT) | Tube | Tube | Tube |
Shared specifications
- Core processor
- PIC
- Core size
- 8-Bit
- Oscillator type
- Internal
- Program memory type
- FLASH
Request a quote on any Microchip Technology PIC12 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Microchip Technology Microchip Technology PIC12 Series variants differ?
- Microchip Technology PIC12 Series part numbers differ by case, connectivity, data converters and EEPROM size. Use the selection guide above to pick by case.
- How many Microchip Technology Microchip Technology PIC12 Series part numbers are listed?
- 100 Microchip Technology Microchip Technology PIC12 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Microchip Technology Microchip Technology PIC12 Series?
- Request a quote (RFQ) for any Microchip Technology PIC12 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
