Microchip Technology 24FC512T-E/Q4B, Automotive AEC-Q100 EEPROM, 512Kbit, I²C 1MHz, 1.7V-5.5V, -40°C to 125°C, 8-UDFN Exposed Pad, Tape & Reel.
| Parameter | Value |
|---|---|
| Series | Automotive, AEC-Q100 |
| Memory type | Non-Volatile |
| Mounting type | Surface Mount |
| Voltage | 1.7V ~ 5.5V |
| Frequency | 1 MHz |
| Memory interface | I²C |
| Operating temperature | -40°C ~ 125°C (TA) |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Technology | EEPROM |
| Access time | 900 ns |
| Memory size | 512Kbit |
| Memory format | EEPROM |
| Case | 8-UFDFN Exposed Pad |
| Memory organization | 64K x 8 |
| Write cycle time - word, page | 5ms |
The Microchip 24FC512T-E/Q4B is a 512Kbit serial EEPROM organized as 64K x 8, communicating over an I²C bus at up to 1 MHz.
Housed in an 8-UDFN with exposed pad (supplier package 8-UDFN 2x3 mm), the part mounts flush to the PCB.
The 24AA128T-I/SN is a smaller-density sibling (128Kbit vs 512Kbit) with the same 900 ns access time and I²C interface, but its operating temperature tops out at 85°C — it does not meet the 125°C automotive grade.
ROHS3 compliance is confirmed. The AEC-Q100 automotive qualification is the primary reliability document — this covers the temperature grade, ESD sensitivity, and PPAP-level data for tier-one ECU programs.
