HX 05-P
LEM USA Inc. · HX Series
SENSOR CURRENT HALL 5A AC/DC
[IN STOCK] In Stock: 3 pcs
MOQ 1 · Tray · RoHS · EIA-481 · DAP/DDP · T/T
Technical specifications
| Parameter / Attribute | Specification / Value |
|---|---|
| Series | HX |
| Sensor type | Hall Effect, Open Loop |
| Mounting | Through Hole |
| Supply voltage | ±15V |
| Current - sensing | 5A |
| Current - supply | 15mA |
| Frequency | 50kHz |
| Response time | 3µs |
| Operating temperature | -25°C ~ 85°C |
| Output | Ratiometric, Voltage |
| Package | Tray |
| Accuracy | ±1% |
| Linearity | ±1% |
| Polarization | Bidirectional |
| For measuring | AC/DC |
| Case | Module |
| Channels | 1 |
HX 05-P
