CYPD2103-20FNXIT USB Type-C Controller, ARM Cortex-M0

MPNCYPD2103-20FNXIT
End of Life

Infineon EZ-PD™ CCG2 series CYPD2103-20FNXIT USB Type-C controller, ARM® Cortex®-M0 core, 32KB Flash, 4K x 8 RAM, 1.71V~5.5V supply, -40°C~85°C, 20-WLCSP (1.63x2.03 mm).

$1.63Ref. price · indicative, final on quote
CYPD2103-20FNXIT datasheet
Packaging20-UFBGA, WLCSP
StockContact for availability
MOQ1 pcs
  • 100% new & originalTraceable channels only — no refurbs, no pulls, no remarked parts.
  • Date & lot codes on quoteStated per line before you commit; label photos on request.
  • MSL-compliant ESD packingMoisture-sealed bags with indicator cards; reels photo-verified.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

CYPD2103-20FNXIT Technical Specifications
ParameterValue
SeriesEZ-PD™ CCG2
Mounting typeSurface Mount
Program memory typeFLASH (32kB)
Voltage1.71V ~ 5.5V
InterfaceI²C, SPI, UART/USART, USB
Operating temperature-40°C ~ 85°C (TA)
PackageTape & Reel (TR); Cut Tape (CT)
RAM size4K x 8
ApplicationsUSB Type C
Number of i (O)9
Core processorARM® Cortex®-M0
Case20-UFBGA, WLCSP

Product details

USB Type-C controller with a Cortex-M0 inside

It integrates the protocol logic for USB Type-C port management, including cable orientation detection and role negotiation, in a single 20-ball WLCSP package measuring 1.63x2.03 mm.

Nine general-purpose I/Os are available for auxiliary signals like VCONN control, dead-battery detection, or status LEDs.

Interface set and system integration

The I²C interface is the typical control channel for reading port status and setting policy; the SPI and UART paths are useful for debug or bridging to legacy peripherals. The 1.71 V minimum supply means it can operate in low-voltage battery systems (e.g., single-cell Li-ion at 3.0 V nominal, down to 1.8 V near end-of-discharge) without a boost converter.

Frequently asked questions

What is the difference between CYPD2103 and CYPD2123?

The CYPD2123 is a different variant in the EZ-PD CCG2 family, but the evidence does not provide its specific specs. The CYPD2103-20FNXIT has 32 KB Flash, 4K x 8 RAM, and 9 I/Os in a 20-WLCSP package. For a pin-compatible alternative with more I/Os, consider the CYPD2122-24LQXIT (24-pin QFN, 14 I/Os, same core and Flash size).
