Active production — what it means for a BOM line
The BSC023N08NS5SCATMA1: ROHS3 compliance is confirmed, which covers the full RoHS exemption set including lead in high-melting-temperature solders — no additional exemption documentation is needed for EU-market builds.
Gate charge and switching frequency budget
Input capacitance measures 6800 pF at 40 V Vds — this sets the Miller plateau duration and the crossover loss during the switching transition; a gate resistor in the 2–10 Ohm range gives a clean turn-on without excessive ringing on the WSON-8 layout.
Thermal and temperature envelope
Junction temperature range spans -55 °C to 175 °C, which covers automotive under-hood and industrial motor-drive environments where the ambient inside the enclosure can reach 85 °C and the MOSFET self-heats another 50–60 °C at full load. The PG-WSON-8-2 package has an exposed drain pad — the thermal resistance to the board depends on the number and size of vias under the pad; a 2x2 array of 0.3 mm vias filled with solder gives about 15–20 °C/W junction-to-ambient on a 2-ounce copper four-layer board.
