Infineon 2EDL8123G3CXTMA1 Half-Bridge Driver, 3A/5A

MPN2EDL8123G3CXTMA1
End of Life

Infineon EiceDriver™ half-bridge gate driver, 2EDL8123G3CXTMA1, 3A source / 5A sink peak output, 120V bootstrap, 8V-17V supply, PG-VSON-10-4 package, Tape & Reel.

$1.67Ref. price · indicative, final on quote
2EDL8123G3CXTMA1 datasheet
Packaging10-VFDFN Exposed Pad
StockIn Stock (14)
Lead time3-5 Days wk
MOQ1 pcs
  • 100% new & originalTraceable channels only — no refurbs, no pulls, no remarked parts.
  • Date & lot codes on quoteStated per line before you commit; label photos on request.
  • MSL-compliant ESD packingMoisture-sealed bags with indicator cards; reels photo-verified.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

2EDL8123G3CXTMA1 Technical Specifications
ParameterValue
Gate typeN-Channel MOSFET
Input typeNon-Inverting
Channel typeIndependent
Mounting typeSurface Mount
Voltage8V ~ 17V
High side voltage - max (Bootstrap)120 V
Current - peak output (Source, sink)3A, 5A
Operating temperature-40°C ~ 125°C (TJ)
PackageTape & Reel (TR); Cut Tape (CT)
Case10-VFDFN Exposed Pad
Number of drivers2
Driven configurationHalf-Bridge
Rise (Fall time)45ns, 45ns

Product details

Half-bridge driver with 3A/5A peak output for N-channel MOSFETs

The 2EDL8123G3CXTMA1: The bootstrap high-side topology derives the floating supply from the low-side switch node, so the 120 V maximum bootstrap voltage sets the ceiling for the DC bus voltage the high-side driver can reference. Supply voltage range is 8 V to 17 V, covering standard 12 V bias rails with margin for transients in industrial power supplies and motor drives.

ROHS3 compliant with no lead exemptions, clearing it for RoHS-regulated markets without a PPID exemption claim.

Frequently asked questions

What is the 2EDL8123G3CXTMA1's peak output current?

The driver delivers 3 A peak source and 5 A peak sink current, sufficient to drive the gate of large N-channel MOSFETs in a half-bridge configuration.

What package does the 2EDL8123G3CXTMA1 come in?

It is supplied in a PG-VSON-10-4 package (10-VFDFN with exposed pad), on Tape & Reel or Cut Tape.

How does the 2EDL8123G3CXTMA1 compare to the 2EDL23N06PJXUMA1?

Both are EiceDriver half-bridge drivers, but the 2EDL23N06PJXUMA1 drives both N-channel and P-channel MOSFETs and has a lower peak output of 1.8 A versus the 2EDL8123G3CXTMA1's 3 A source / 5 A sink. The 2EDL23N06PJXUMA1 also has a wider temperature range to 150°C. They are not pin-compatible — the 2EDL8123G3CXTMA1 uses the PG-VSON-10-4 package while the 2EDL23N06PJXUMA1 uses a different footprint.
