DIGITAL ISOLATORS
$2.49Ref. price · indicative, final on quote
Packaging8-SOIC (0.154", 3.90mm Width)
StockContact for availability
MOQ1 pcs
- 100% new & originalTraceable channels only — no refurbs, no pulls, no remarked parts.
- Date & lot codes on quoteStated per line before you commit; label photos on request.
- MSL-compliant ESD packingMoisture-sealed bags with indicator cards; reels photo-verified.
- PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
Specifications
| Parameter | Value |
|---|---|
| Type | General Purpose |
| Channel type | Unidirectional |
| Mounting type | Surface Mount |
| Voltage | 2.7V ~ 6.5V |
| Voltage - isolation | 3000Vrms |
| Isolated power | No |
| Operating temperature | -40°C ~ 150°C |
| Pulse width distortion | 4ns |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Data rate | 40Mbps |
| Technology | Capacitive Coupling |
| Case | 8-SOIC (0.154\", 3.90mm Width) |
| Number of channels | 2 |
| Inputs - side 1/Side 2 | 2/0 |
| Rise (Fall time) | 4ns, 4ns (Max) |
| Propagation delay tpLH (tpHL) | 33ns, 33ns |
| Common mode transient immunity | 100kV/µs |
