EPC EPC2 Dc Dc Modules Series

5 variants · EPCAll DC-DC Power Modules →

About the EPC EPC2 Dc Dc Modules Series

The EPC EPC2 Dc Dc Modules Series series groups 5 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common case of Die, operating temperature of -40°C ~ 150°C (TJ) and package of Tape & Reel (TR); Cut Tape (CT). Variants differ by current - continuous drain (Id) @ 25°C, drain to source voltage and FET type, so you can match the exact current - continuous drain (Id) @ 25°C your application requires using the selection guide below. All listed EPC EPC2 Dc Dc Modules Series part numbers are active and orderable.

Select a variant by

Current - continuous drain (Id) @ 25°C: 1.7A (Ta) · 3.4A · 5A (Ta) · 10A (Ta), 40A (Ta) · 23A
Drain to source voltage: 30V · 60 V · 100V · 120V · 200 V
FET type: 2 N-Channel (Dual) Common Source · 2 N-Channel (Half Bridge) · N-Channel
Gate charge (Qg) (Max) @ vgs: 0.8nC @ 5V · 1.15 nC @ 5 V · 1.3 nC @ 5 V · 4.9nC @ 15V, 19nC @ 15V · 7nC @ 5V
Input capacitance (Ciss) (Max) @ vds: 80pF @ 60V · 115 pF @ 30 V · 140 pF @ 100 V · 475pF @ 15V, 1960pF @ 15V · 800pF @ 50V
Rds on (Max) @ id, vgs: 6.3mOhm @ 20A, 5V · 8.2mOhm @ 25A, 5V, 2.1mOhm @ 25A, 5V · 45mOhm @ 1A, 5V · 60mOhm @ 4A, 5V · 100mOhm @ 3A, 5V
Vgs(th) (Max) @ id: 2.5V @ 1mA · 2.5V @ 4mA, 2.5V @ 16mA · 2.5V @ 5.5mA · 2.5V @ 700µA · 2.5V @ 800µA

Shared specifications

Case: Die
Operating temperature: -40°C ~ 150°C (TJ)
Package: Tape & Reel (TR); Cut Tape (CT)

Variant comparison

Parameter	EPC2012C	EPC2035	EPC2100	EPC2104	EPC2110
Current - continuous drain (Id) @ 25°C	5A (Ta)	1.7A (Ta)	10A (Ta), 40A (Ta)	23A	3.4A
Drain to source voltage	200 V	60 V	30V	100V	120V
FET type	N-Channel	N-Channel	2 N-Channel (Half Bridge)	2 N-Channel (Half Bridge)	2 N-Channel (Dual) Common Source
Gate charge (Qg) (Max) @ vgs	1.3 nC @ 5 V	1.15 nC @ 5 V	4.9nC @ 15V, 19nC @ 15V	7nC @ 5V	0.8nC @ 5V
Input capacitance (Ciss) (Max) @ vds	140 pF @ 100 V	115 pF @ 30 V	475pF @ 15V, 1960pF @ 15V	800pF @ 50V	80pF @ 60V
Rds on (Max) @ id, vgs	100mOhm @ 3A, 5V	45mOhm @ 1A, 5V	8.2mOhm @ 25A, 5V, 2.1mOhm @ 25A, 5V	6.3mOhm @ 20A, 5V	60mOhm @ 4A, 5V
Vgs(th) (Max) @ id	2.5V @ 1mA	2.5V @ 800µA	2.5V @ 4mA, 2.5V @ 16mA	2.5V @ 5.5mA	2.5V @ 700µA

Request a quote on any EPC EPC2 Dc Dc Modules Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
