Diodes Incorporated DPS1135FIA-13
MPNDPS1135FIA-13
End of Life
IC PWR SWITCH N-CH V-QFN4040-17
$1.53Ref. price · indicative, final on quote
Packaging17-VFQFN Exposed Pad
RoHSROHS3 Compliant
Independent supplier — new & surplus stockAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Input type | Non-Inverting |
| Output type | N-Channel |
| Type | General Purpose |
| Mounting | Surface Mount |
| Voltage - load | 4.5V ~ 24V |
| Voltage - supply (Vcc (Vdd)) | Not Required |
| Output current | 5A |
| I/O channels | 1 |
| Interface | On/Off |
| Operating temperature | -40°C ~ 125°C (TJ) |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Features | Load Discharge, Slew Rate Controlled, Status Flag |
| Rds on | 30mOhm |
| Case | 17-VFQFN Exposed Pad |
| Fault protection | Current Limiting (Adjustable), Over Temperature, Over Voltage, Reverse Current, Short Circuit, UVLO |
| Output configuration | High Side |
| Ratio - Input:Output | 1:1 |
