XGL3530-331MEC
Coilcraft
[IN STOCK] In Stock: 31 pcs
MOQ 1 · Strip · RoHS · EIA-481 · DAP/DDP · T/T
Technical specifications
| Parameter / Attribute | Specification / Value |
|---|---|
| Type | Molded |
| Series | XGL3530 |
| Mounting | Surface Mount |
| Current rating | 18.5 A |
| Current - saturation | 9.1A |
| Frequency - self resonant | 160MHz |
| Inductance frequency - test | 1 MHz |
| Operating temperature | -40°C~125°C |
| Size (Dimension) | 0.138\" L x 0.126\" W (3.50mm x 3.20mm) |
| Height - seated | 0.118\" (3.00mm) |
| Package | Strip |
| Ratings | AEC-Q200 |
| Shielding | Shielded |
| Tolerance | ±20% |
| Inductance | 330 nH |
| Case | Nonstandard |
| DC resistance | 4.6mOhm Max |
XGL3530-331MEC
