Coilcraft MSS1260H-103MED
MPNMSS1260H-103MED
Active
$3.3500Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Type | Drum Core |
| Series | MSS1260H |
| Mounting | Surface Mount |
| Current rating | 3.9 A |
| Current - saturation | 7A |
| Frequency - self resonant | 26MHz |
| Inductance frequency - test | 100 kHz |
| Operating temperature | -40°C ~ 125°C |
| Material - core | Ferrite |
| Size (Dimension) | 0.472\" L x 0.472\" W (12.00mm x 12.00mm) |
| Height - seated | 0.246\" (6.25mm) |
| Package | Strip |
| Ratings | AEC-Q200 |
| Shielding | Shielded |
| Tolerance | ±20% |
| Inductance | 10 µH |
| Case | Nonstandard |
| DC resistance | 19.3mOhm Max |
